Image is an illustration, may not reflect the exact product sold.


Other products by Telewave

Telewave - ANT-450D - 406-512 MHz 1-2.6 dBd Folded Dipole Antenna 71Deg VBW

  • MFR SKU: ANT-450D
  • ITEM #: 2769090
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $649.64 You Save: $114.97
17.70 % OFF
$534.67
  • +
    -
Stock Status: In Stock

ITEM #: 2769090
The Telewave ANT450D consists of single element dipole antenna witha precision phasing harness for optimum performance. The antennahorizontal pattern is field adjustable for any current or futurecoverage requirements. The wide bandwidth and high efficiency ofthese antennas make them ideal for many applications includingtrunking business public safety government and amateur radio.Eachdipole element is constructed with 6061-T6 aluminum and welded atthe base for maximum strength. Each antenna is also...
ITEM #: 2769090
The Telewave ANT450D consists of single element dipole antenna witha precision phasing harness for optimum performance. The antennahorizontal pattern is field adjustable for any current or futurecoverage requirements. The wide bandwidth and high efficiency ofthese antennas make them ideal for many applications includingtrunking business public safety government and amateur radio.Eachdipole element is constructed with 6061-T6 aluminum and welded atthe base for maximum strength. Each antenna is also completely sealedwith our high-tech Txylan coating which resists water and icebuildup and provides exceptional protection from corrosive gases UVradiation salt spray acid rain and windblown abrasives. The phasingharness is fully sealed by Telewaves Millenium Sealtechnology.All components are at DC ground potential forlightning protection. Each dipole element includes a heavy-duty custom clamp set for mounting to a 1.5-2.5 diameter galvanized steel support pipe or tower leg.
Read More >>

Telewave - ANT-450D - 406-512 MHz 1-2.6 dBd Folded Dipole Antenna 71Deg VBW

  • Item #: 2769090
  • MFR SKU: ANT-450D
  • 406-512 MHz Unity Gain Exposed Dipole Antenna. The Telewave ANT450 D series consists of single, dual, and 4-element dipole array antennas with a precision phasing harness for optimum performance. The antenna horizontal pattern is field adjustable, for any current or future coverage requirements. The wide bandwidth and high efficiency of these antennas make them ideal for many applications, including trunking, business, public safety, government, and amateur radio. Specifications Specific Frequency: 406-512
  • MHz Antenna Pattern: Adjustable Gain d Bd: 1 d Bd / 2.5 d Bd Gain d Bi: 3.1 d Bi / 4.6 d Bi Polarization: Vertical Vertical Beamwidth: 71 deg Horizontal Beamwidth: 66 deg Maximum VSWR: 1.5:1 Maximum Power: 500
  • W Lightning Protection: DC Ground RF Connectors: N
  • Male Connector: Placement Pigtail Jumper Included: Yes
  • Type of Hardware Included: Clamp set for 1.5-2.5" OD Maximum Rated: Wind Velocity 175 mile/h Item Height: 13 in
  • Item Length: 12 in
  • Item Weight: 6 lb
