Techlite Insulation - 0079-0075IP100-PF-0000-00 - Pipe Insulation: Melamine, Hinged, 1 in Thick, 1 1/8 in ID, For 3/4 in Pipe, 4 ft Lg, Unfaced, Gray

  • MFR SKU: 0079-0075IP100-PF-0000-00
  • ITEM #: 5314492
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $60.10 You Save: $9.15
15.22 % OFF
$50.95
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 5314492
These melamine foam insulation tubes cover a length of straight pipe or tubing. They are factory cut-to-length and preformed to save fabrication time in the field.

Techlite Insulation - 0079-0075IP100-PF-0000-00 - Pipe Insulation: Melamine, Hinged, 1 in Thick, 1 1/8 in ID, For 3/4 in Pipe, 4 ft Lg, Unfaced, Gray

  • Item #: 5314492
  • MFR SKU: 0079-0075IP100-PF-0000-00
  • Insulation Material: Melamine
  • Form: Tube
  • Installation Style: Hinged
  • For Pipe Size: 3/4 in
  • Inside Diameter: 1-1/8 in
  • Outside Diameter: 3-1/8 in
  • Overall Length: 4 ft
  • Thickness: 1 in
  • Insulation R-Value: 6.18
  • Minimum Operating Temperature: -40 ° F
  • Maximum Operating Temperature: 350 ° F
  • Facing Material: Unfaced
  • Foam Cell Type: Open
  • Sealing Method: Self-Sealing Adhesive Strip
  • Includes: Preformed Pipe Insulation
  • Features: Excellent Antibacterial and Wash Down Properties
  • Color: Gray
  • Density: 0.44 +/- 0.19 lb/cu ft
  • Flexibility: Flexible
  • K Value: 0.27 BTU @ 75° F
  • Jacket Thickness: 0.02 in
  • Plenum Rating: Plenum Rated
  • Smoke Developed Index: 50
  • Flame Spread Index: 25
  • Standards: ASTM E84
  • Brand: TECHLITE INSULATION
  • UNSPSC: 30141505
  • Country of Origin: USA (subject to change)
