Taco - 007-F5 - Hydronic Circulating Pump: Std, Taco, Flanged, 1/25 HP, 10 ft Max. Head, 6 3/8 in Face to Face

  • MFR SKU: 007-F5
  • ITEM #: 5314560
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $270.75 You Save: $31.81
11.75 % OFF
$238.94
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 5314560
Taco 007-F5 Flanged Cast Iron Hydronic Circulator 115V
The Taco 007-F5 Cartridge Circulator is field serviceable and design is compact, provides quiet operation and unmatched reliability. Self-lubricating, maintenance free design and flow characteristics make it the ideal hydronic circulator for a wide range of applications. Wet-rotor, in-line single-stage circulator pump. Ideal for hydronic heating, radiant heating, hydro-air fan coils, indirect water heaters, chilled fresh water and domestic...
ITEM #: 5314560
Taco 007-F5 Flanged Cast Iron Hydronic Circulator 115V
The Taco 007-F5 Cartridge Circulator is field serviceable and design is compact, provides quiet operation and unmatched reliability. Self-lubricating, maintenance free design and flow characteristics make it the ideal hydronic circulator for a wide range of applications. Wet-rotor, in-line single-stage circulator pump. Ideal for hydronic heating, radiant heating, hydro-air fan coils, indirect water heaters, chilled fresh water and domestic water recirculation systems. Made using cast iron casing with a non-metallic impeller and stainless steel cartridge. EPDM o-ring and gaskets. Carbon bearings and ceramic shaft. UL listed. Also available in bronze construction with universal flange-to-flange dimensions.
Read More >>

Taco - 007-F5 - Hydronic Circulating Pump: Std, Taco, Flanged, 1/25 HP, 10 ft Max. Head, 6 3/8 in Face to Face

  • Item #: 5314560
  • MFR SKU: 007-F5
  • br> Weights & Dimensions
  • Head Max 10 ft
  • Suction Draw Head 10 ft
  • Inlet Connection NPT 3/4, 1, 1-1/4, 1-1/2 in
  • Product Details
  • Voltage 115 v
  • Pump Type Yes
  • Max Operating Pressure 125 psi
  • Temperature Range 40-240 °f
  • Horsepower 1/25 HP
  • Amperage 0.71 A
  • RPM 3250 rpm
  • Phase 1
  • Compatible Part/Model Number 007-F3 & 007-F4
  • Type Flange Not Included
  • Warranty 3 yr
  • Material Cast Iron
  • Respirator Connection Type Flanged
