Image is an illustration, may not reflect the exact product sold.


Other products by Suntec

Suntec - J4NB-A1000G - Model J Single-Stage Fuel Unit , RH-LH, 1725 RPM, 26 GPH, 40 psi

  • MFR SKU: J4NB-A1000G
  • ITEM #: 17776246
  • 12345
  • 0 Reviews / 0 Questions
$433.35
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 17776246
Suntec J4NB-A1000G Waste Oil Boost Pump 18 GPH 20-40 PSISpecifications:Inlet port (2 ports possible) 1/4 NPTFReturn port 1/4 NPTFNozzle outlet 1/8 NPTFPressure gauge port Use other inlet port. Bleeder valve port 1/8 NPSFExternal pressure regulator needed No. Cut-off Yes hydraulic only. Strainer 8 sq in open area. Shaft diameter 7/16 in. Hydraulic Data. Nozzle pressure range 20-40 psi. Factory pressure setting 40 psi***See Note*** Rated nozzle flow 26 GPH @ 40 psi 1725 rpm (# 2 fuel oil) 58 GPH @...
ITEM #: 17776246
Suntec J4NB-A1000G Waste Oil Boost Pump 18 GPH 20-40 PSISpecifications:Inlet port (2 ports possible) 1/4 NPTFReturn port 1/4 NPTFNozzle outlet 1/8 NPTFPressure gauge port Use other inlet port. Bleeder valve port 1/8 NPSFExternal pressure regulator needed No. Cut-off Yes hydraulic only. Strainer 8 sq in open area. Shaft diameter 7/16 in. Hydraulic Data. Nozzle pressure range 20-40 psi. Factory pressure setting 40 psi***See Note*** Rated nozzle flow 26 GPH @ 40 psi 1725 rpm (# 2 fuel oil) 58 GPH @ 40 psi 3450 rpm (# 2 fuel oil).Oil temperature 50 - 115 FInlet/return pressure 10 psi max. Operating vacuum Single pipe : 6 Hg max. to prevent air separation from oil Motor Speed 1725 rpm or 3450 rpm***Note***Flow Rates Based On # 2 Fuel Oil. Heavy Oil # 4 And Lighter As Well As Waste Oil Will Have Varying Flow Rates Depending On Viscosity. Replaces J3NBN-A132B J3NBNA132BSpecifications:J - SINGLE STAGE4 - .340N - 8 SQ. IN OPEN AREAB - R.H. Rot. L.H. Noz.A - 20-40 PSI 1.4-2.8 BARS100 - FLANGE MOUNTING STYLEG - Glasgow KY ModelJ4N
Read More >>

Suntec - J4NB-A1000G - Model J Single-Stage Fuel Unit , RH-LH, 1725 RPM, 26 GPH, 40 psi

  • Item #: 17776246
  • MFR SKU: J4NB-A1000G
  • br> Weights & Dimensions
  • Depth 6-3/5 in
  • Width 3-5/8 in
  • Height 4-3/5 in
  • Weight 4.2 lbs
  • Product Details
  • Pump Type Single Stage
  • Nozzle Capacity @ Rated PSI 26 gal/hr
  • Shaft Speed 1725 rpm
  • Rotation & Nozzle Location RH-LH
  • Warranty 1 yr
  • Color Family Black
  • Rated Pressure 40 psi
