Shinybow - SB-1116G - Shinybow SB-1116 1x16 VGA Distribution Amplifier - 2048 x 2048 - 440 MHzMaximum Video Bandwidth - 150 ft Maximum Operating Distance - VGA In - VGA Out

  • MFR SKU: SB-1116G
  • ITEM #: 3828898
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $475.00 You Save: $71.25
15.00 % OFF
$403.75 & Free Shipping
  • +
    -
Stock Status: SHIPS SOON(reserve your unit today)
Average lead time for this brand: 2-3 weeks. Specific products may vary.

ITEM #: 3828898

The SB-1116 provides (16) VGA outputs that are identical to the source signal. This is useful for distributing high resolution VGA signals from one computer to (16) different monitors. This ultrahigh speed current feedback amplifier with an excellent 5500V/as slew rate results in a rise time of 545ps, making it ideal as a pulse amplifier. The high slew rate lowers the effect of slew rate limiting and results in the large signal bandwidth of 440MHz (G=+2), a small signal bandwidth of (-3dB) 1000MHz...

ITEM #: 3828898

The SB-1116 provides (16) VGA outputs that are identical to the source signal. This is useful for distributing high resolution VGA signals from one computer to (16) different monitors. This ultrahigh speed current feedback amplifier with an excellent 5500V/as slew rate results in a rise time of 545ps, making it ideal as a pulse amplifier. The high slew rate lowers the effect of slew rate limiting and results in the large signal bandwidth of 440MHz (G=+2), a small signal bandwidth of (-3dB) 1000MHz (G=+1) delivers computer resolutions up to 2048x2048 at distances up to 150 feet away without signal deterioration. Signal quality is maintained over a wide bandwidth with worst-case distortion of -40dBc@250MHz (G=+10, 1Vp-p). Input and output connectors are HD-15 female type. The SB-1116 is housed in a 19 inch rack mountable metal case, (1) RU high. All units are +12VDC powered, a power adaptor is included.

Read More >>

Shinybow - SB-1116G - Shinybow SB-1116 1x16 VGA Distribution Amplifier - 2048 x 2048 - 440 MHzMaximum Video Bandwidth - 150 ft Maximum Operating Distance - VGA In - VGA Out

  • Item #: 3828898
  • MFR SKU: SB-1116G
  • Package Contents:
    • SB-1116 1x16 VGA Distribution Amplifier
    • Rack Mount Kit
    • Users Guide
    • AC/DC Adapter: 12VDC@1250mA
  • Product Type: Video Distribution Amplifier
  • Product Type: Video Distribution Amplifier
  • Input Voltage: 12 V DC
  • Manufacturer Part Number: SB-1116G
  • Manufacturer Website Address: http://www.shinybowusa.com
  • Packaged Quantity: 1
  • Weight (Approximate): 5.30 lb
  • Manufacturer: Shinybow Technology
  • Product Model: SB-1116
  • Product Name: SB-1116 1x16 VGA Distribution Amplifier
  • Brand Name: Shinybow
  • Brand Name: Shinybow
  • Height: 1.8"
  • Width: 8"
  • Depth: 17.3"
  • Number of VGA Outputs: 16
  • Number of VGA Inputs: 1
  • Environmentally Friendly: Yes
  • Maximum Video Resolution: 2048 x 2048
  • Maximum Operating Distance: 150 ft
  • Number of VGA Outputs: 16
  • VGA In: Yes
  • VGA Out: Yes
  • Number of VGA Inputs: 1
  • Maximum Video Bandwidth: 440 MHz
