Schneider Electric - BDA160201 - Circuit breaker, PowerPacT B, 20A, 1 pole, 600Y/347VAC, 14kA, I-Line, thermal magnetic, 80%, A, ( Each )

MFR SKU: BDA160201

ITEM #: 23174313

- 0 out of 5 stars
- 5 Star
  0 %
- 4 Star
  0 %
- 3 Star
  0 %
- 2 Star
  0 %
- 1 Star
  0 %
0 Reviews / 0 Questions

Lists At: $438.00 You Save: $176.60

$261.40

Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 23174313
PowerPacT B-Frame brings thermal-mechanical circuit protection in a compact size and offers a wide range of accessories, auxiliaries, and connection options. This PowerPacT B-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600Y/347VAC. All PowerPacT B-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT B-Frame circuit breakers come in 1 to 4-pole unit mount construction and in 1 to 3-pole I-Line construction. I-Line circuit breakers come with a shrouded I-Line plug on jaw. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT B, 20A, 1 pole, circuit breaker has a breaking capacity of 14kA at 600Y/347VAC. This circuit breaker has a continuous current rating of 80% with an A phase connection. PowerPacT B circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
This listing is for Each.

Schneider Electric - BDA160201 - Circuit breaker, PowerPacT B, 20A, 1 pole, 600Y/347VAC, 14kA, I-Line, thermal magnetic, 80%, A, ( Each )

Item #: 23174313

MFR SKU: BDA160201

Technical Specs

ECCN EAR99
Country of Origin MX - Mexico
UPC 360648117231
UNSPSC 39121616
Standard NEMA AB1 || CSA C22.2 No 5 || EN/IEC 60947-2 || UL 489 || NMX J-266 || GB 14048.2 || EN/IEC 60947-5-1
Mounting Type I-Line
Color Gray RAL 7016
AWG Range AWG 14...AWG 2/0 aluminium/copper
Current Rating 20-20A

Rated Voltage 240V AC 50/60 Hz UL 489
Torque 3.6-4.4 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5-6.2 N.m 10-70 mm² (AWG 8...AWG 2/0)
Color Family Gray
Length 20 mm
Height 38.1 mm
Depth 89 mm
Width 27 mm
No. of Poles 1
