Schneider Electric - 8501KPR13P14V20 - SCHNEIDER General Purpose Relay: Socket Mounted, 10 A Current Rating, 120V AC, 11 Pins/Terminals

MFR SKU: 8501KPR13P14V20

ITEM #: 23190668

- 0 out of 5 stars
- 5 Star
  0 %
- 4 Star
  0 %
- 3 Star
  0 %
- 2 Star
  0 %
- 1 Star
  0 %
0 Reviews / 0 Questions

Lists At: $124.60 You Save: $24.65

$99.95

Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 23190668
Class 8501 type KP, 3C/O, 10A universal relay. Relay includes clear cover, LED indicator, cylindrical terminal connection and 120 Vac coil.
8501KP universal plug in relays are designed for multipole switching applications at 300 VAC or lower. These relays are designed to be plugged into a relay socket. This makes for very easy replacement. This relay plugs into an 851NR61 or 8501NR62 relay socket. This relay has a DPDT contact arrangements. It has two normally open and two normally closed contacts. The contacts have a 10 ampere rating 277 VAC, a 10 ampere rating at 28 VDC, a 1/3 HP rating at 120 VAC, a 1 HP rating at 277 VAC and a B300 inductive rating. Relays can be ordered with a wide variety of coil voltages. This relay has a 120 VAC nonreplaceable coil. A green LED indicator is supplied on this relay. 8501KP relays are UL listed with Square D relay sockets, UL component recognized and CSA certified.
This listing is for Each.
