Ruland - FSMR19-8-5-SS - RULAND MANUFACTURING Motion Control Coupling: 3 Angular Misalignment, 8 mm Bore Dia 1, Set Screw, 1

  • MFR SKU: FSMR19-8-5-SS
  • ITEM #: 7687757
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $173.50 You Save: $21.55
12.42 % OFF
$151.95
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)
Average lead time for this brand: 1-2 weeks. Specific products may vary.

ITEM #: 7687757
General purpose set screw beam shaft couplings feature a set screw collar on each end to securely attach the coupled shafts. They are suitable for use in servo and stepper motors where zero backlash is required.
WARNING: Cancer and Reproductive Harm -

Ruland - FSMR19-8-5-SS - RULAND MANUFACTURING Motion Control Coupling: 3 Angular Misalignment, 8 mm Bore Dia 1, Set Screw, 1

  • Item #: 7687757
  • MFR SKU: FSMR19-8-5-SS
  • Brand: RULAND MANUFACTURING
  • Manufacturer Part Number: FSMR19-8-5-SS
  • Zero Backlash: Yes
  • Shaft Locking Type: Set Screw
  • System of Measurement: Metric
  • Different Bore Sizes: Yes
  • Bore Type: Round
  • Bore Diameter 1: 8 mm
  • Bore Diameter 2: 5 mm
  • Bore Tolerance: +0.025/-0.000 mm
  • Length Through Bore 1: 15.4 mm
  • Length Through Bore 2: 15.4 mm
  • Shaft Tolerance: +0.000/-0.013 mm
  • Coupling Outside Diameter: 19.1 mm
  • Overall Length: 31.8 mm
  • Number of Beams: 6
  • Maximum Speed: 6, 000 RPM
  • Rated Torque: 3.51 N-m
  • Dynamic Torque Non-Reversing: 1.76 N-m
  • Dynamic Torque Reversing: 0.88 N-m
  • Torsional Stiffness: 1.18 N-m/Deg
  • Moment of Inertia: 0.000002964 kgf/m sq
  • Coupling Material: Stainless Steel
  • Coupling Material Grade: 303
  • Coupling Material Finish: Bright
  • For Misalignment Type: Angular; Axial; Parallel
  • Angular Misalignment: 3 °
  • Axial Motion: 0.13 mm
  • Parallel Misalignment: 0.2 mm
  • Minimum Operating Temperature: -40 ° C
  • Maximum Operating Temperature: 176 ° C
  • Application: Light-Duty Power Transmission; Servo Motors to Lead Screws
  • Features: Balanced Design for Reduced Vibration
  • Standards: Conflict Minerals Compliant; DIN 912 12.9; REACH Compliant; RoHS3 Compliant
  • For Environment: Angular Misalignment; Axial Motion; Parallel Misalignment
  • Full Bearing Support Required: Yes
  • Number of Locking Screws: 2
  • Included Screws: (2) Set Screw
  • Fastener Tightening Torque: 1.76 N-m
  • Screw Thread Size: M4
  • Screw Material: Alloy Steel
  • Screw Material Finish: Black Oxide
  • UNSPSC: 31163003
  • Country of Origin: USA (subject to change)
