RTcom - OBHD-2C - HDMI Fiber Optic TX/RX Modules using single or multimode fiber

ITEM #: 3790247
This is RT-Com USA's latest iteration of our high performance and cost-effective line of fiber optic extenders for digital video. Our unique optical conversion technology enables noise-free and high resolution (1080p) extension up to 6500ft while compliant to HDCP. Because it uses only fiber optic cable, external emf and rf interference will not degenerate the signal. This version can be used with either single-mode or multi-mode fiber cables . MAIN FEATURES Optimized for HDTV (HDCP Compliant) Separate HDMI transmitter and receiver modules are connected with LC connectors. Supports high resolutions 480p, 720p/1080i, 1080p, 1920* 1200@60Hz Extends up to 2 kilometers- single mode optional. Uncompressed digital video & audio signal. Supports manual EDID programming as well as preprogrammed factory EDID Corresponds to T.M.D.S. signal. External 5V power supply adapter included. HDMI copper cable (2m) 2pcs included. APPLICATIONS Video Wall Systems Large LED Sign Boards Medical Imaging Equipment Airplane On-board Video Systems Home Theaters TV Broadcast Stations Auditoriums Conference Room Video Equipment Church Video Systems TECHNICAL SPECIFICATIONS Digital Video Bandwidth : 25~225 MHz (HDMI single link) Video Resolution : Up to 1080P@60Hz with Deep Color and HBR audio Connector Type : HDMI Type Optical source : 1310/1550nm BiDi OSA Optical Cable Type : 50/125 or 62.5/125 LC Multi-mode Fiber 9/125 LC Single Mode Two external 5V power supply adapter included Power Supply : DC 5, 2.0A Power Consumption : Transmitter 3.35 Watts(Max.) Receiver 4.18 Watts(Max.) Operating Temperature & Humidity : 0-40*C, Less than 80% Humidity DIMENSIONS (mm) OBHD-2C - 132mm (5.2 in) * 106mm (4.17 in) * 30mm (1.18 in) (W*D*H)
