RME Audio - FIREFACE UCX II - FIREFACE UCX II 40-Channel 192 kHz Advanced USB 2.0 Audio Interface with MIDI / ADAT / AES / EBU & SPDIF I/Os

MFR SKU: FIREFACE UCX II

ITEM #: 22412125

- 0 out of 5 stars
- 5 Star
  0 %
- 4 Star
  0 %
- 3 Star
  0 %
- 2 Star
  0 %
- 1 Star
  0 %
0 Reviews / 0 Questions

Lists At: $1,999.00 You Save: $300.00

$1,699.00

Stock Status: SHIPS SOON(reserve your unit today)

ITEM #: 22412125
FIREFACE UCX II 40-Channel 192 kHz Advanced USB 2.0 Audio Interface with MIDI / ADAT / AES / EBU & SPDIF I/Os

RME Audio - FIREFACE UCX II - FIREFACE UCX II 40-Channel 192 kHz Advanced USB 2.0 Audio Interface with MIDI / ADAT / AES / EBU & SPDIF I/Os

Item #: 22412125

MFR SKU: FIREFACE UCX II

Technical Specs

Specifications:

Analog - AD, Line In 5-8, rear
Resolution AD: 24 bit
Signal to Noise ratio (SNR): 112 dB RMS unweighted, 115 dBA
Frequency response @ 44.1 k. Hz, -0.1 dB: 5 Hz - 20.8 k. Hz
Frequency response @ 96 k. Hz, -0.5 dB: 3 Hz - 45.8 k. Hz
Frequency response @ 192 k. Hz, -1 dB: 2 Hz - 92 k. Hz
THD: < -110 dB, < 0.00032 %
THD+N: < -104 dB, 110 dB
Input: 6.3 mm TRS jack, electronically balanced
Input impedance: 8 k. Ohm unbalanced, 12 k. Ohm balanced
Input sensitivity switchable to +19 d. Bu and +13 d. Bu
Variable gain: 0 to +12 dB
Minimum level for 0 dBFS: +1 d. Bu, -1.2 dBV: Line In 3-4, front
Additional Gain stage: 0 up to +12 dB
Maximum input level, +19 d. Bu, Gain 0 dB: Line +19 d. Bu, Inst +13 d. Bu
Maximum input level, +13 d. Bu, Gain 12 dB: Line +1 d. Bu, Inst -5 d. Bu
Input impedance: Instrument 1 MOhm. Line 13 k. Ohm balanced, 9 k. Ohm unbalanced
Input Gain Inst: +6 dB
Input mode: Line balanced (TRS), Inst unbalanced (TS): Mic In 1-2, front
Input impedance: 5.4 k. Ohm
Gain range: 75 dB
Maximum input level, Gain 0 dB: +18 d. Bu
Maximum input level, Gain 75 dB: -57 d. Bu
EIN: -128 d. Bu A-weighted, 60 dB gain, 150 Ohm, 20 Hz - 20 k. Hz: Line In 1-2
Input: TRS, electronically balanced
Input impedance: 10 k. Ohm balanced, 5 k. Ohm unbalanced
Maximum input level, Gain 0 dB: +24 d. Bu
Maximum input level, Gain 75 dB: -51 d. Bu: DA, Line Out 1-6, rear
Resolution: 24 bit
Dynamic range (DR): 112 dB RMS unweighted, 115 dBA
Frequency response @ 44.1 k. Hz, -0.5 dB: 5 Hz - 20.8 k. Hz
Frequency response @ 96 k. Hz, -0.5 dB: 5 Hz - 45 k. Hz
Frequency response @ 192 k. Hz, -1 dB: 5 Hz - 89 k. Hz
THD: < -108 dB, < 0.0004 %
THD+N: < -104 dB, 110 dB
Maximum output level: +19 d. Bu
Output: 6.3 mm TRS jack, servo-balanced
Output impedance: 75 Ohm

Output level switchable +19 d. Bu, +13 d. Bu, +4 d. Bu: DA - Stereo Monitor Output Phones (7-8)
Output: 6.3 mm TRS stereo jack, unbalanced
Maximum output level at 0 dBFS, High: +19 d. Bu
Maximum output level at 0 dBFS, Low: +4 d. Bu
Output impedance: 1 Ohm
Max power per channel @ 32 Ohm load, 0.1% THD: 210 mW (2.6 Vrms, +10.5 d. Bu): MIDI
1 x MIDI I/O via 5-pin DIN jacks
Galvanically isolated by optocoupled input
Hi-speed mode: Jitter and response time typically below 1 ms
Separate 128 byte FIFOs for input and output: Digital
Clocks: Internal, ADAT, AES, SPDIF, word clock
Jitter suppression of external clocks: > 50 dB (2.4 k. Hz)
Effective clock jitter influence on AD and DA conversion: near zero
PLL ensures zero dropout, even at more than 100 ns jitter
Digital Bitclock PLL for trouble-free varispeed ADAT operation
Supported sample rates: 28 k. Hz up to 200 k. Hz: Digital Inputs - AES/EBU
1 x XLR, transformer-balanced, galvanically isolated, according to AES3-1992
High-sensitivity input stage ( 50 dB (2.4 k. Hz): SPDIF coaxial
1 x RCA, according to IEC 60958
High-sensitivity input stage ( 50 dB (2.4 k. Hz): ADAT
1 x TOSLINK, format according to Alesis specification
Standard: 8 channels 24 bit, up to 48 k. Hz
Double Speed (S/MUX): 4 channels 24 bit 96 k. Hz
Quad Speed (S/MUX4): 2 channels 24 bit 192 k. Hz: Word Clock
BNC
Max. output voltage: 5 Vpp
Output voltage @ 75 Ohm termination: 4.0 Vpp
Output impedance: 10 Ohm
Frequency range: 27 k. Hz - 200 k. Hz: General
Power supply: external power supply
Typical power consumption: 13 Watts
Current at 12 Volt operating voltage: 910 mA (11 Watts)
Dimensions incl. rack ears, full depth (WxHxD):10.5" x 1.73" x 6.1"
Dimensions without rack ears, body depth (WxHxD): 8.5" x 1.73" x 5.1"
Weight: 2.0 lbs
Temperature range: 41° F up to 122° F
Relative humidity: < 75%, non condensing
