GDS-2204A Digital Storage Oscilloscope Specs: Channels: 4Ch + EXT Bandwidth: DC-200MHz (-3dB) / 1.75ns / 20/100MHz Series Features: /70MHz Bandwidth, 2 or 4 Input Channels 2GSa/s Maximum Real-Time Sampling Rate and l00GSa/s Equivalent Time Sampling Rate 2Mega Points Record Length 1mV /div to 10V/div of Vertical Range 1ns/div to 100s/div of Time Base Range VPO Technology to Display Less-Frequently-Occurred Signals Fast Update Rate of 80, 000 Waveform Per Second Built-in Segmented Memory and Waveform...
100 MHz, 1 GSa/s sample rate 2 Channels 800 x 480 pixel widescreen 7" TFT color display Long waveform memory up to 40, 000 points Five different math functions – Add, Subtract, Multiply, Divide, and FFT Alternating triggering capabilities, pulse width, line-selectable video and slope 32 automatic measurements Advanced tools include digital filter with adjustable limits, pass/fail testing, and waveform recorder mode 12 different language user interfaces and context sensitive help EDU mode...
MSO5000 Series Mixed Signal Oscilloscopes MSO5074 Features: Analog bandwidth: 70 MHz; bandwidth upgrade option supported 4 analog channels (upgradable), standard 16 digital channels(LA probe required) Up to 8 GSa/s real-time sample rate 100 Mpts (200 Mpts memory depth option) High waveform capture rate (over 500, 000 wfm/s) Auto measurement of 41 waveform parameters; full-memory hardware measurement function A variety of serial protocol triggers and decodes Up to 450, 000 frames of hardware real-time...
The 2560B Digital Storage (DSO) and Mixed Signal Oscilloscope (MSO) Series offers 100 MHz, 200 MHz and 350 MHz bandwidth models in a 4-channel configuration, with a sample rate of 2 GSa/s and a maximum memory depth of 200 Mpts. Additionally, these oscilloscopes are equipped with a large 10.1" capacitive touch display that provide 1024 x 600 resolution and intuitive touchscreen gestures. The 2560B series extends its debugging capabilities with new software features including zone triggers, Bode...
SDS1204X-E Super Phosphor Oscilloscope Features: 200 MHz Bandwidth 4 Channels 1 GSa/s Sampling Rate Capture rate: 100, 000 wfm/s (normal mode), 400, 000 wfm/s (sequence mode) Memory depth: 14 Mpts (single-channel); 7 Mpts/CH (dual-channel) Math co-processor speeds front panel operation Serial trigger and decoder I2C, SPI, UART, CAN, LIN On-screen Bode plot and web-browser control (standard on 4 channel only) USB Host, USB Device, LAN, Pass/Fail, Trigger Out, Sbus(Siglent MSO) 7 inch TFT–LCD...
MSO5000 Series Mixed Signal Oscilloscopes MSO5354 Features: Analog bandwidth: 350 MHz; bandwidth upgrade option supported 4 analog channels (upgradable), standard 16 digital channels(LA probe required) Up to 8 GSa/s real-time sample rate 100 Mpts (200 Mpts memory depth option) High waveform capture rate (over 500, 000 wfm/s) Auto measurement of 41 waveform parameters; full-memory hardware measurement function A variety of serial protocol triggers and decodes Up to 450, 000 frames of hardware real-time...
The 2560B Digital Storage (DSO) and Mixed Signal Oscilloscope (MSO) Series offers 100 MHz, 200 MHz and 350 MHz bandwidth models in a 4-channel configuration, with a sample rate of 2 GSa/s and a maximum memory depth of 200 Mpts. Additionally, these oscilloscopes are equipped with a large 10.1" capacitive touch display that provide 1024 x 600 resolution and intuitive touchscreen gestures. The 2560B series extends its debugging capabilities with new software features including zone triggers, Bode...
The 2560B Digital Storage (DSO) and Mixed Signal Oscilloscope (MSO) Series offers 100 MHz, 200 MHz and 350 MHz bandwidth models in a 4-channel configuration, with a sample rate of 2 GSa/s and a maximum memory depth of 200 Mpts. Additionally, these oscilloscopes are equipped with a large 10.1" capacitive touch display that provide 1024 x 600 resolution and intuitive touchscreen gestures. The 2560B series extends its debugging capabilities with new software features including zone triggers, Bode...
20MHz bandwidth Peak detect function for 50ns glitch capture XY mode Five automatic measurements: frequency, duty cycle, average, peak to peak, RMS Waveform math: add, subtract, multiply, divide Average mode for smoothing waveforms Extech's MS420 20 MHz 2-Channel Digital Oscilloscope offers a range of capabilities for effective troubleshooting of electronics and electronically controlled electrical systems. With 20 MHz bandwidth and conveniences like auto-set which optimizes the position, range,...
MSO5000 Series Mixed Signal Oscilloscopes MSO5104 Features: Analog bandwidth: 100 MHz; bandwidth upgrade option supported 4 analog channels (upgradable), standard 16 digital channels(LA probe required) Up to 8 GSa/s real-time sample rate 100 Mpts (200 Mpts memory depth option) High waveform capture rate (over 500, 000 wfm/s) Auto measurement of 41 waveform parameters; full-memory hardware measurement function A variety of serial protocol triggers and decodes Up to 450, 000 frames of hardware real-time...
SDS2104X Plus Super Phosphor Oscilloscope Features: 100 MHz Bandwidth 4 + EXT Channels 2 GSa/s Sampling rate 500, 000 wfm/s Capture rate 200 Mpts/ch Memory depth Serial bus triggering and decoder, supports I2C, SPI, UART/RS232, CAN, LIN USB Host, USB Device, LAN, External trigger, Auxiliary output (TRIG OUT, PASS/FAIL) 10.1 inch TFT-LCD with capacitive touch screen (1024x600) The SDS2000X Plus Series employs SPO (Super Phosphor Oscilloscope) technology, 256-level intensity grading display function...
MSO8000 Series Digital Oscilloscope - Self-developed ASIC Chip and UltraVision II Deliver Uncompromised Performance at an Affordable Price MSO8104 Features: Analog bandwidth: 1 GHz (single-channel and half-channel modes) 4 analog channels, 1 EXT channel, and 16 standard configuration of digital channels (required to purchase the probe) Up to 10 GSa/s real-time sample rate Up to 500 Mpts memory depth (standard) High waveform capture rate (over 600, 000 waveforms per second) Up to 450, 000 frames...
GDS-2104A Digital Storage Oscilloscope Specs: Channels: 4Ch + EXT Bandwidth: DC-100MHz (-3dB) / 3.5ns / 20MHz Series Features: /70MHz Bandwidth, 2 or 4 Input Channels 2GSa/s Maximum Real-Time Sampling Rate and l00GSa/s Equivalent Time Sampling Rate 2Mega Points Record Length 1mV /div to 10V/div of Vertical Range 1ns/div to 100s/div of Time Base Range VPO Technology to Display Less-Frequently-Occurred Signals Fast Update Rate of 80, 000 Waveform Per Second Built-in Segmented Memory and Waveform Search...
DS1000E Series Digital Oscilloscopes Product Features: Dual analog channels and 16 channels logic analyzer, 100MHz maximum bandwidth, 1GSa/s maximum real-time sample rate and 25GSa/s maximum equivalent sample rate 5.6 inch 64k TFT LCD makes the waveform displays more clear and vivid Abundant trigger types: Edge, Pulse Width, Video, Slope, Alternate, Pattern and Duration Unique adjustable trigger sensitivity enables to meet different demands Enable to measure 22 types of wave parameters and track...
GDS-2202A Digital Storage Oscilloscope Specs: Channels: 2Ch + EXT Bandwidth: DC-200MHz (-3dB) / 1.75ns / 20/100MHz Series Features: /70MHz Bandwidth, 2 or 4 Input Channels 2GSa/s Maximum Real-Time Sampling Rate and l00GSa/s Equivalent Time Sampling Rate 2Mega Points Record Length 1mV /div to 10V/div of Vertical Range 1ns/div to 100s/div of Time Base Range VPO Technology to Display Less-Frequently-Occurred Signals Fast Update Rate of 80, 000 Waveform Per Second Built-in Segmented Memory and Waveform...
GDS-2304A Digital Storage Oscilloscope Specs: Channels: 4Ch + EXT Bandwidth: DC-300MHz (-3dB) / 1.17ns / 20M/100M/200MHz Series Features: /70MHz Bandwidth, 2 or 4 Input Channels 2GSa/s Maximum Real-Time Sampling Rate and l00GSa/s Equivalent Time Sampling Rate 2Mega Points Record Length 1mV /div to 10V/div of Vertical Range 1ns/div to 100s/div of Time Base Range VPO Technology to Display Less-Frequently-Occurred Signals Fast Update Rate of 80, 000 Waveform Per Second Built-in Segmented Memory and...
MSO5000 Series Mixed Signal Oscilloscopes MSO5204 Features: Analog bandwidth: 200 MHz; bandwidth upgrade option supported 4 analog channels (upgradable), standard 16 digital channels(LA probe required) Up to 8 GSa/s real-time sample rate 100 Mpts (200 Mpts memory depth option) High waveform capture rate (over 500, 000 wfm/s) Auto measurement of 41 waveform parameters; full-memory hardware measurement function A variety of serial protocol triggers and decodes Up to 450, 000 frames of hardware real-time...
DS1000Z-E Series Digital Oscilloscopes Product Features: Two Analog Channels DS1102Z-E 100 MHz Bandwidth, (DS1202Z-E 200 MHz) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts(Std.) Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions Low noise floor, vertical scale range: 500 uV/div to 10 V/div Various interfaces: USB Host & Device, LAN...
The 2560B Digital Storage (DSO) and Mixed Signal Oscilloscope (MSO) Series offers 100 MHz, 200 MHz and 350 MHz bandwidth models in a 4-channel configuration, with a sample rate of 2 GSa/s and a maximum memory depth of 200 Mpts. Additionally, these oscilloscopes are equipped with a large 10.1" capacitive touch display that provide 1024 x 600 resolution and intuitive touchscreen gestures. The 2560B series extends its debugging capabilities with new software features including zone triggers, Bode...
DS1000Z-E Series Digital Oscilloscopes Product Features: Two Analog Channels DS1202Z-E 200 MHz Bandwidth, (DS1102Z-E 100 MHz) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts(Std.) Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions Low noise floor, vertical scale range: 500 uV/div to 10 V/div Various interfaces: USB Host & Device, LAN...
200, 100, 70 MHz Bandwidth models; 2- or 4-Channels 1 GSa/s Real-Time Sampling Rate for Each Channel (2 ch. models); 1 GSa/s Maximum Real-Time Sampling Rate (4 ch models) Standard 10M Maximum Memory Depth and VPO Waveform Display Technology Waveform Update Rate of 120, 000 wfm/s 8" WVGA TFT LCD Display FFT with Maximum 1M points to Provide Higher Frequency Domain Resolution Measurement High and Low Pass Digital Filter Functions 29, 000 Sections of Segmented Memory and Waveform Search Functions...
RIGOL DS8000-R Series Compact Digital Oscilloscope The DS8204-R digital oscilloscope adopts RIGOL's self developed chipset "Phoenix", which can gain the data acquisition capability of up to 10 GSa/s sample rate, realizing the high integration of all the function modules required for the analog front-end (AFE), and greatly improving the consistency and reliability of the digital oscilloscope. The innovative UltraVision II platform delivers a higher waveform capture rate, full digital trigger...
DS1000Z Series Digital & Mixed Signal Oscilloscopes Product Features: Analog channel bandwidth: 100 MHz, 70 MHz, 50 MHz 4 analog channels, 16 digital channels (only available for DS1000Z Plus that has been upgraded with the MSO upgrade option) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions...
2194 Digital Storage Oscilloscope, 4 Channel Features: Bandwidth: 100 MHz Channels: 4 Maximum Sample Rate: 1 GSa/s 2 Maximum Memory Depth: 14 Mpts Waveform Update Rate: 100, 000 wfms/s Vertical Resolution: 8-bit Display: 7“ TFT 800 x 480 FFT: 128 kpts and 7 additional math operations Decoding: I2C, UART, SPI, CAN, LIN User Interface: USB host, USB device, LAN Includes: Power cord (1), USB cable (1), passive probe (4), and certificate of calibration. Highlights: Color temperature display mode...
DS1000Z Series Digital & Mixed Signal Oscilloscopes Product Features: Analog channel bandwidth: 100 MHz, 70 MHz, 50 MHz 4 analog channels, 16 digital channels (only available for DS1000Z Plus that has been upgraded with the MSO upgrade option) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions...
DS1000Z Series Digital & Mixed Signal Oscilloscopes Product Features: Analog channel bandwidth: 100 MHz, 70 MHz, 50 MHz 4 analog channels, 16 digital channels (only available for DS1000Z Plus that has been upgraded with the MSO upgrade option) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions...
DS1000Z Series Digital & Mixed Signal Oscilloscopes Product Features: Analog channel bandwidth: 100 MHz, 70 MHz, 50 MHz 4 analog channels, 16 digital channels (only available for DS1000Z Plus that has been upgraded with the MSO upgrade option) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions...
MSO2000A & DS2000A OSCILLOSCOPESProduct Features:Bandwidth up to 300 MHz, standard with 50 Ω input 2 analog channels, 16 digital channels (MSO) Lower noise floor, wider vertical range: 500 uV/div~10 V/div Real-time Sample Rate: analog channel up to 2 GSa/s, digital channel up to 1 GSa/s (MSO) Memory Depth: analog channel up to 14 Mpts (standard)/56 Mpts (optional), digital channel up to 14 Mpts (standard)/28 Mpts (optional, MSO) Innovative "UltraVision" technology Waveform capture...
MSO7000 & DS7000 Series Digital & Mixed Signal Oscilloscopes Product Features: Analog bandwidth: 500 MHz, 350 MHz, 200 MHz, and 100 MHz; bandwidth upgrade option supported 4 analog channels, 1 EXT channel, and 16 digital channels (Option) Up to 10 GSa/s real-time sample rate Up to 500 Mpts memory depth (Option) High waveform capture rate (over 600, 000 waveforms per second) Up to 450, 000 frames of hardware real-time and ceaseless waveforms recording and playback functions Integrates 7 independent...
MSO2000A & DS2000A OSCILLOSCOPESProduct Features:Bandwidth up to 300 MHz, standard with 50 Ω input 2 analog channels, 16 digital channels (MSO) Lower noise floor, wider vertical range: 500 uV/div~10 V/div Real-time Sample Rate: analog channel up to 2 GSa/s, digital channel up to 1 GSa/s (MSO) Memory Depth: analog channel up to 14 Mpts (standard)/56 Mpts (optional), digital channel up to 14 Mpts (standard)/28 Mpts (optional, MSO) Innovative "UltraVision" technology Waveform capture...
MSO7000 & DS7000 Series Digital & Mixed Signal Oscilloscopes Product Features: Analog bandwidth: 500 MHz, 350 MHz, 200 MHz, and 100 MHz; bandwidth upgrade option supported 4 analog channels, 1 EXT channel, and 16 digital channels (Option) Up to 10 GSa/s real-time sample rate Up to 500 Mpts memory depth (Option) High waveform capture rate (over 600, 000 waveforms per second) Up to 450, 000 frames of hardware real-time and ceaseless waveforms recording and playback functions Integrates 7 independent...
300/200/100MHz bandwidth selections ;2 channels Real time sample rate is 2GSa/s max. Per Channel 20M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented memories and waveform search functions I2C/UART/CAN/LIN serial bus trigger and decoding function Data log function is able to track signal changes...
MSO8000 Series Digital Oscilloscope - Self-developed ASIC Chip and UltraVision II Deliver Uncompromised Performance at an Affordable Price MSO8204 Features: Analog bandwidth: 2 GHz (single-channel and half-channel modes) 4 analog channels, 1 EXT channel, and 16 standard configuration of digital channels (required to purchase the probe) Up to 10 GSa/s real-time sample rate Up to 500 Mpts memory depth (standard) High waveform capture rate (over 600, 000 waveforms per second) Up to 450, 000 frames...
MSO2000A & DS2000A OSCILLOSCOPESProduct Features:Bandwidth up to 300 MHz, standard with 50 Ω input 2 analog channels, 16 digital channels (MSO) Lower noise floor, wider vertical range: 500 uV/div~10 V/div Real-time Sample Rate: analog channel up to 2 GSa/s, digital channel up to 1 GSa/s (MSO) Memory Depth: analog channel up to 14 Mpts (standard)/56 Mpts (optional), digital channel up to 14 Mpts (standard)/28 Mpts (optional, MSO) Innovative "UltraVision" technology Waveform capture...
200 MHz, 4-Channels Built-in instrumentation: 500 MHz Spectrum Analyzer 25 MHz Arbitrary Waveform Generator (MDO-2204EX) Digital Multimeter 5V/1A Power Supply Real Time Sample rate per channel: 1 GSa/s 10 M Memory depth per channel w/ VPO Waveform Display Technology Waveform Update Rate: to 120, 000 wfm/s 8" WVGA TFT LCD Display Maximun 1M FFT provides higher frequency domain resolution measurements High Pass, Low Pass, Band Pass filter functions 29, 000 Segmented Memory Search Functions I2C/SPI/UART/CAN/LIN...
CLICK HERE to view the RIGOL Oscilloscopes and Real-Time Spectrum Analyzers PageRIGOL DS8000-R Series Compact Digital Oscilloscope The DS8034-R digital oscilloscope adopts RIGOL's self developed chipset "Phoenix", which can gain the data acquisition capability of up to 10 GSa/s sample rate, realizing the high integration of all the function modules required for the analog front-end (AFE), and greatly improving the consistency and reliability of the digital oscilloscope. The innovative...
GDS-1102B Digital Storage Oscilloscope Specs: 100MHz, 2 Channel Includes: User manual CD, power cord, GTP-100B-4 100MHz Passive Probe GDS-1000B Series Features: 200/100/70MHz bandwidth selections, 2ch input 100/70/50MHz bandwidth selections, 4ch input 1GSa/s maximum sampling rate 10M maximum memory depth for each channel 7-inch 800 x 480 WVGA LCD display 256 color gradient display function to strengthen waveform performance I2C/SPI/UART/CAN/LIN serial bus trigger and decoding functions 1Mpts FFT...
MSO7000 & DS7000 Series Digital & Mixed Signal Oscilloscopes Product Features: Analog bandwidth: 500 MHz, 350 MHz, 200 MHz, and 100 MHz; bandwidth upgrade option supported 4 analog channels, 1 EXT channel, and 16 digital channels (Option) Up to 10 GSa/s real-time sample rate Up to 500 Mpts memory depth (Option) High waveform capture rate (over 600, 000 waveforms per second) Up to 450, 000 frames of hardware real-time and ceaseless waveforms recording and playback functions Integrates 7 independent...
100MHz, 4-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented...
100MHz, 2-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG, 5, 000 count DMM and power supply Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass...
200MHz, 2-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented...
70MHz, 2-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented...
300/200/100MHz bandwidth selections ;2 channels Real time sample rate is 2GSa/s max. Per Channel 20M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented memories and waveform search functions I2C/UART/CAN/LIN serial bus trigger and decoding function Data log function is able to track signal changes...
SDS2204X Plus Super Phosphor Oscilloscope Features: 200 MHz Bandwidth 4 + EXT Channels 2 GSa/s Sampling rate 500, 000 wfm/s Capture rate 200 Mpts/ch Memory depth Serial bus triggering and decoder, supports I2C, SPI, UART/RS232, CAN, LIN USB Host, USB Device, LAN, External trigger, Auxiliary output (TRIG OUT, PASS/FAIL) 10.1 inch TFT-LCD with capacitive touch screen (1024x600) The SDS2000X Plus Series employs SPO (Super Phosphor Oscilloscope) technology, 256-level intensity grading display function...
The DS70504 5GHz High Performance 4 Channel Digital Oscilloscopes In today's integrated design field, a highly integrated comprehensive digital oscilloscope has become an important tool for design engineers. RIGOL's DS70000 series oscilloscope integrates 5 independent instruments into 1 including a digital oscilloscope, one spectrum analyzer, one digital voltmeter, one high precision frequency counter and totalizer, and one protocol analyzer. The DS70000 series provides a comprehensive instrument...
DS1000Z Series Digital & Mixed Signal Oscilloscopes Product Features: Analog channel bandwidth: 100 MHz, 70 MHz, 50 MHz 4 analog channels, 16 digital channels (only available for DS1000Z Plus that has been upgraded with the MSO upgrade option) Real-time sample rate up to 1 GSa/s Memory depth up to 24 Mpts Up to 30, 000 wfms/s waveform capture rate Up to 60, 000 frames hardware real-time waveform recording and playback functions Innovative UltraVision technology Various trigger and bus decoding functions...
MSO7000 & DS7000 Series Digital & Mixed Signal Oscilloscopes Product Features: Analog bandwidth: 500 MHz, 350 MHz, 200 MHz, and 100 MHz; bandwidth upgrade option supported 4 analog channels, 1 EXT channel, and 16 digital channels (Option) Up to 10 GSa/s real-time sample rate Up to 500 Mpts memory depth (Option) High waveform capture rate (over 600, 000 waveforms per second) Up to 450, 000 frames of hardware real-time and ceaseless waveforms recording and playback functions Integrates 7 independent...
100MHz, 2-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG, 5, 000 count DMM and power supply Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass...
200MHz, 4-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented...
300/200/100MHz bandwidth selections ;2 channels Real time sample rate is 2GSa/s max. Per Channel 20M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented memories and waveform search functions I2C/UART/CAN/LIN serial bus trigger and decoding function Data log function is able to track signal changes...
SDS5034X Digital Storage Oscilloscope Features: 350 MHz Bandwidth 4 + EXT Channels 5 GSa/s Real-time sampling rate Capture Rate: 110, 000 wfm/s (normal mode), 500, 000 wfm/s (sequence mode) Memory: 250 Mpts (single-channel), 125 Mpts (dual-channel) Serial bus triggering and decoder, supports I2C, SPI, UART, CAN, LIN, CAN FD, Flexray, I2S and MIL-STD-1553B USB Host, USB Device, LAN, Pass/Fail, Trigger Out, 10 MHz In, 10 MHz Out, VGA Output 10.1 inch TFT-LCD with capacitive touch screen (1024*600)...
SDS1104X-E Super Phosphor Oscilloscope Features: 100 MHz Bandwidth 4 Channels 1 GSa/s Sampling Rate Capture rate: 100, 000 wfm/s (normal mode), 400, 000 wfm/s (sequence mode) Memory depth: 14 Mpts (single-channel); 7 Mpts/CH (dual-channel) Math co-processor speeds front panel operation Serial trigger and decoder I2C, SPI, UART, CAN, LIN On-screen Bode plot and web-browser control (standard on 4 channel only) USB Host, USB Device, LAN, Pass/Fail, Trigger Out, Sbus(Siglent MSO) 7 inch TFT–LCD...
SDS6054A Digital Storage Oscilloscope, 500MHz, 4 Analog Channels Features: 5 GSa/s (10 GSa/s ESR) per channel Record Length up to 500 Mpts Waveform capture rate up to 750, 000 wfm/s (Sequence mode) 4 Math traces (8 Mpts FFT, addition, subtraction, multiplication, division, integration, differential, square root, etc.), supports formula editor Low background noise, supports 0.5 mV/div to 10 V/div vertical scales Large 12.1 inch TFT-LCD display w/capacitive touch screen supporting multimulti-touch...
100MHz, 2-ch, DSO, Spectrum analyzer, dual channel 25MHz AWG Real time sample rate for each channel is 1GSa/s (2 channel models) Maximum real time sample rate is 1GSa/s (4 channel models) Per Channel 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Free Frequency Response Analyzer Software Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented...
Key Features 200 MHz, 2-Channels 16-channel logic analyzer Dual-channel 25 MHz arbitrary waveform generator Maximum sample rate: 1GSa/s Maximum 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8" WVGA TFT LCD screen display Maximum 1M FFT provides higher frequency domain resolution measurements High Pass, Low Pass and Band Pass Filter Functions 29, 000 segmented memory sections and waveform search function I2C/SPI/UART/CAN/LIN serial bus trigger...
300/200/100MHz bandwidth selections ;2 channels Real time sample rate is 2GSa/s max. Per Channel 20M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented memories and waveform search functions I2C/UART/CAN/LIN serial bus trigger and decoding function Data log function is able to track signal changes...
300/200/100MHz bandwidth selections ;2 channels Real time sample rate is 2GSa/s max. Per Channel 20M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8 “ WVGA TFT LCD display Maximum 1M FFT provides higher frequency domain resolution measurements High , low and band pass filter functions 29, 000 segmented memories and waveform search functions I2C/UART/CAN/LIN serial bus trigger and decoding function Data log function is able to track signal changes...
SDS2204X HD 4 Channel 200 MHz Digital Storage Oscilloscope SIGLENT’s SDS2000X HD Series high resolution digital storage oscilloscopes are based on 2 GSa/s, 12-bit Analog-Digital Convertors and front ends with excellent noise floor performance. They are available in bandwidths of 350 MHz, 200 MHz and 100 MHz, have maximum record length of 200 Mpts/ch, and display 4 analog channels + 16 digital channels mixed signal analysis ability. SDS2000X HD More Power Video Key Features 12-bit High Resolution...
SDS2354X Plus Super Phosphor Oscilloscope Features: 350 MHz(upgradable to 500 MHz) 4 + EXT Channels 2 GSa/s Real Time Sampling Rate 500, 000 wfm/s Capture Rate 200 Mpts/ch Memory Depth Serial Trigger and decode, standard: I2C, SPI, UART/RS232, CAN, LIN Math function (2 Mpts FFT, addition, subtraction, multiplication, division, integration, differential, square root) 10.1 inch TFT LCD with capacitive touch screen (1024x600) Interface: USB 2.0 Host x2, USB 2.0 Device, LAN, External trigger, Auxiliary...
Global Specialties DSC-5300 Digital Storage Oscilloscope Features and Specifications Bandwidth: 50 MHz Single channel real-time sampling rate of up to 500 MSa/s 32k points of memory depth 7-inch Color TFT LCD display Trigger types: Edge, Pulse, Video, Slope and Alternative Auto measure 32 parameters (Voltage and Time) On board help menu Interface Options: USB, LAN, RS-232, Pass/Fail The Global Specialties DSC-5300 digital storage oscilloscope (DSO) is a portable benchtop instrument used for making...
The DS70304 3GHz High Performance 4 Channel Digital Oscilloscopes In today's integrated design field, a highly integrated comprehensive digital oscilloscope has become an important tool for design engineers. RIGOL's DS70000 series oscilloscope integrates 5 independent instruments into 1 including a digital oscilloscope, one spectrum analyzer, one digital voltmeter, one high precision frequency counter and totalizer, and one protocol analyzer. The DS70000 series provides a comprehensive instrument...
GDS-1104B Digital Storage Oscilloscope Specs: 100MHz, 4 Channel Includes: User manual CD, power cord, GTP-100B-4 100MHz Passive Probe GDS-1000B Series Features: 200/100/70MHz bandwidth selections, 2ch input 100/70/50MHz bandwidth selections, 4ch input 1GSa/s maximum sampling rate 10M maximum memory depth for each channel 7-inch 800 x 480 WVGA LCD display 256 color gradient display function to strengthen waveform performance I2C/SPI/UART/CAN/LIN serial bus trigger and decoding functions 1Mpts FFT...
100 MHz, 4-Channels 16-channel logic analyzer Dual-channel 25 MHz arbitrary waveform generator Maximum sample rate: 1GSa/s Maximum 10M memory depth and VPO waveform display technology Waveform update rate up to 120, 000 wfms/s 8in WVGA TFT LCD screen display Maximum 1M FFT provides higher frequency domain resolution measurements High Pass, Low Pass and Band Pass Filter Functions 29, 000 segmented memory sections and waveform search function I2C/SPI/UART/CAN/LIN serial bus trigger and decoding functions...
GDS-1202B Digital Storage Oscilloscope Specs: 200MHz, 2 Channels Includes: User manual CD, power cord, GTP-200B-4 200MHz Passive Probe GDS-1000B Series Features: 200/100/70MHz bandwidth selections, 2ch input 100/70/50MHz bandwidth selections, 4ch input 1GSa/s maximum sampling rate 10M maximum memory depth for each channel 7-inch 800 x 480 WVGA LCD display 256 color gradient display function to strengthen waveform performance I2C/SPI/UART/CAN/LIN serial bus trigger and decoding functions 1Mpts FFT...
