Newco - 04-16F-CB2 - NEWCO Gate Valve: 4 in, Carbon Steel, Rising, Class 600 Flange, 1, 495 psi Max. Pressure (CWP), Wheel

  • MFR SKU: 04-16F-CB2
  • ITEM #: 5693900
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $2,558.00 You Save: $528.56
20.66 % OFF
$2,029.44
  • +
    -
  • Saw It For Less?
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 5693900
Rising-stem carbon steel general purpose gate valves have handwheels and stems that lift as the valve opens to keep the stem away from the fluid path and visually indicate whether the valve is open or closed.

Newco - 04-16F-CB2 - NEWCO Gate Valve: 4 in, Carbon Steel, Rising, Class 600 Flange, 1, 495 psi Max. Pressure (CWP), Wheel

  • Item #: 5693900
  • MFR SKU: 04-16F-CB2
  • For Media: Gas; Oil; Steam; Water
  • Body Material: Carbon Steel
  • Nominal Valve Size: 4 in
  • ANSI Flange Class: Class 600
  • Max. Pressure (CWP): 1, 495 psi
  • Max. Pressure (Steam): 840 psi
  • Coefficient of Volume (Cv): 1, 297
  • Handle Type: Wheel
  • Handle Material: Cast Iron; Ductile Iron
  • Stem Type: Rising
  • Stem Material: 410 Stainless Steel
  • Wedge Style: Flexible
  • Wedge Material: 410 Stainless Steel
  • Seat Material: Metal
  • Seal Material: Graphite
  • Bonnet Material: Carbon Steel
  • Bonnet Style: Bolted
  • Connection Type: Class 600 Flange
  • Connection Size - Side 1: 4 in
  • Connection Type - Side 1: Flange
  • Connection Size - Side 2: 4 in
  • Connection Type - Side 2: Flange
  • Media Temp. Range: -20 ° F to 800 ° F
  • Operating Temperature - Minimum: -20 ° F
  • Operating Temperature - Maximum: 800 ° F
  • Standards: API 598; ASME
  • Brand: NEWCO
  • Number of Flange Bolt Holes: 8
  • Overall Length: 17 in
  • Handle Height: 26.91 in
  • Manufacturer Part Number: 04-16F-CB2
  • UNSPSC: 40141613
  • Country of Origin: China (subject to change)
