Image is an illustration, may not reflect the exact product sold.


Other products by Nachi

Nachi - 6017C3 - 85mm x 130mm x 22.0mm 6017C3 Open Deep Groove Ball Bearing

  • MFR SKU: 6017C3
  • ITEM #: 16505013
  • 12345
  • 0 Reviews / 0 Questions
Currently Not In Stock
This product appears to have been discontinued, however, other similar products may be available. Our product specialists would be happy to research this for you and provide recommendations. Email me suggestions!

ITEM #: 16505013
85mm x 130mm x 22.0mm 6017C3 Open Deep Groove Ball Bearing

Nachi - 6017C3 - 85mm x 130mm x 22.0mm 6017C3 Open Deep Groove Ball Bearing

  • Item #: 16505013
  • MFR SKU: 6017C3
  • Bore Size 85mm
  • Clearance C3: 0.030 - 0.058 mm
  • Dynamic Load Bearing 49500 N
  • Enclosure Type OPEN
  • Finish Unfinished
  • Lubricant Type Prelubricated
  • Material Steel
  • Number of Rows Single Row
  • Outer Diameter 130mm
  • Precision Class P0, ABEC 1
  • Speed 5000 rpm (Grease), 6000 rpm (Oil)
  • Static Load Bearing 43000 N
  • Style High Speed
  • Temperature -20° C - 120° C
  • Type Deep Groove Ball Bearing
  • Width 22.0mm
  • Product Weight 1.97
  • Notes
  • Single Row Deep Groove Ball Bearings are the most common bearing type in the world due to their versatility and performance. These bearings are available in a variety of seal, shield and snap-ring arrangements. Bearings with seals or shields are standardized and already contain the proper amount of grease. Open bearings will require lubrication. These bearings can sustain radial and/or axial loads and because of their simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation.
  • Excellent High Speed Capability. Good Radial Load Capacity. Good Axial Load Capacity in both directions. Low Torque Requirements during startup and operation. Low Noise. Little/No Maintenance Required.
  • These bearings are used for General Purpose, Industrial Machinery, Motors, Conveyors, Gearboxes, Auto Aftermarket and all types of equipment.
