Moline Bearing - 19341300 - MOLINE BEARING Pillow Block Bearing: 3 in Bore, Fixed, Cast Iron, 3 1/8 in Shaft Ht, 4 Holes

  • MFR SKU: 19341300
  • ITEM #: 26713796
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $1,163.00 You Save: $283.41
24.37 % OFF
$879.59
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 26713796
Solid housing pillow block tapered roller bearings install quickly, requiring no assembly prior to use.

Moline Bearing - 19341300 - MOLINE BEARING Pillow Block Bearing: 3 in Bore, Fixed, Cast Iron, 3 1/8 in Shaft Ht, 4 Holes

  • Item #: 26713796
  • MFR SKU: 19341300
  • Brand: MOLINE BEARING
  • Manufacturer Part Number: 19341300
  • Bearing Insert Type: Tapered Roller
  • Bearing Insert Material: Alloy Steel
  • Bearing Material Grade: 52100
  • Shaft Locking Type: Set Screws
  • Bore Diameter: 3 in
  • Bore Type: Cylindrical
  • Mount Type: Bolt-Through
  • Number of Mount Holes: 4
  • Mounting Surface to Shaft Center Height: 3-1/8 in
  • Mount Hole Center-to-Center Length: 9-1/2 in
  • Mount Hole Center-to-Center Width: 2-1/8 in
  • Mount Hole Size: 7/8 in
  • Mounting Bolt Size: 5/8 in
  • Included Bearing: Timken Type E Tapered Roller
  • Expansion Type: Fixed
  • Housing Type: Solid
  • Housing Material: Cast Iron
  • Overall Length: 12 in
  • Overall Width: 4.5 in
  • Overall Height: 6.25 in
  • Base Height: 1.88 in
  • Base Width: 4 in
  • Load Direction: Radial; Thrust
  • Dynamic Axial Load Capacity: 12, 300 lbf
  • Static Radial Load Capacity: 61, 200 lbf
  • Maximum Speed: 1, 965 RPM
  • Seal Type: Contact
  • Lubricant Material: Lithium Complex Grease
  • Maximum Temperature: 250 ° F
  • Minimum Temperature: -40 ° F
  • Features: Assembled, Adjusted and Pre-Lubricated in Advance for Immediate Use; Built with Timken ™ Enhanced Dee Tapered Roller Bearings with the Highest Industry Load Ratings, Double-Extended Inner Race, Case Hardened Rollers and Races; Close Fit Oversized Collars Act as Flingers for Additional Protection in Dusty or Damp Environments; Dimensionally Interchangeable with Comparable Type E Units, Moline Split E1000, Moline ME2000 and ME3000; Extended Inner Race has Two Locking Collars with 65° Set Screw Spacing; Misalignment = .010 in Per Foot of Shaft; Standard V-Guard™ Nitrile and Teflon Contact Seal or Balanced Labyrinth Seal; Timken™ Lithium Complex Grease Operating Temperature is up to 250°, High Temperature Grease is Available up to 350°
  • Application: Aggregate; Conveying; Cranes; Forestry; Mining; Oil, Gas, Power Generation; Screening
  • Includes: Timken Type E Tapered Roller Bearing
  • UNSPSC: 31171511
  • Country of Origin: USA (subject to change)
