Miller Electric - 951668 - Miller Electric 951668 Dynasty® 200 DX

ITEM #: 5112106
Miller Electric 951668 Dynasty® 200 DX Multi-Process Welder Foot Control Package; 210A
Miller Electric Dynasty® 200 DX Multi-Process Welder Foot Control Package ; Rated Output: 210A at 18V, 60% Duty Cylcle; Frequency Rating: 50/60 Hz; Overall Height: 13.6 Inch; Overall Width: 8.6 Inch; Overall Depth: 22.5 Inch; OCV: 80VDC; Amperage Rating: 1 - 210A; Voltage Rating: 120 - 480V; Phase: 1-Phase/3-Phase; Process: AC/DC TIG (GTAW), Pulsed TIG (GTAW-P), Stick (SMAW)
A perfect combination of sophisticated inverter technology and advanced features, offering the most flexible AC/DC TIG/Stick power supply in the welding industry.
• The DX model offers full AC features, including advanced waveforms and wide ranges of balance and frequency.
• Front panel memory card data port provides the ability to easily upgrade software and expand product features. Visit /tigsoftware for the latest software upgrades and expansions.
• Auto-Line power management technology a llows hookup to either single-phase or three-phase electrical input from 120-460 V with no manual linking, providing convenience in any job setting. An ideal solution for dirty or unreliable input power.
• Pro-Set feature eliminates the guesswork when setting weld parameters. Use Pro-Set when you want the speed, convenience and confidence of pre-set controls. Simply select the feature and adjust until Pro-Set appears on the display. The Pro-Set feature is available for Balance, Frequency, Pulse and DIG parameters.
• Stick features include t ailored arc control (DIG) allows the arc characteristic to be changed for specific applications and electrodes. Smooth running 7018 or stiffer, more penetrating 6010. Hot Start™ adaptive control provides positive arc starts without sticking. Stick-Stuck detects if the electrode is stuck to the part and turns the welding output off to safely and easily remove the electrode. Menu selectable.
This listing is for 1
