Miller Electric - 951000001 - Miller Multimatic 215 Single Phase CC/CV Multi-Process Welder With 120 - 240 Input Voltage, Welding Cart, Auto-Set Elite Technology And Accessory Package, ( Each )

  • MFR SKU: 951000001
  • ITEM #: 25919665
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $4,066.00 You Save: $563.90
13.87 % OFF
$3,502.10
  • +
    -
  • Saw It For Less?
Stock Status: SHIPS SOON (reserve your unit today)
Average lead time for this brand: 1-2 weeks. Specific products may vary.

ITEM #: 25919665
Item Details Easy-to-use and versatile MIG, Stick and DC TIG welder that helps build skills. Color screen featuring Auto-Set Elite. This all-in-one welder connects to 120 or 240 volt input power. Welds up to 3/8- mild steel. Features Multiprocess capabilities allow for MIG, flux-cored, DC TIG and DC stick welding Intuitive color LCD user interface makes it quick and easy to adjust parameters. Auto-Set Elite can be used on multiple material sand multiple processes with the ability to finetune your...
ITEM #: 25919665
Item Details Easy-to-use and versatile MIG, Stick and DC TIG welder that helps build skills. Color screen featuring Auto-Set Elite. This all-in-one welder connects to 120 or 240 volt input power. Welds up to 3/8- mild steel. Features Multiprocess capabilities allow for MIG, flux-cored, DC TIG and DC stick welding Intuitive color LCD user interface makes it quick and easy to adjust parameters. Auto-Set Elite can be used on multiple material sand multiple processes with the ability to finetune your settings. Easy to set up and use Multi-voltage plug (MVP) allows connection to common 120- and 240-volt power receptacles without the use of any tools--choose the plug that fits the receptacle and connect it to the power cord Angled cast-aluminum drive system with Quick Select drive roll for smooth feeding and quick wire changes Smooth-Start for consistently smooth, spatter-free MIG starts Auto Spool Gun Detect automatically detects when a MIG gun or spool gun is connected, eliminating the need for a switch Fan-On-Demand cooling system only operates when needed, reducing noise, energy use and the amount of contaminants pulled through the machine Thermal overload protection automatically shuts down the power source if airflow through the unit is blocked or the Duty Cycle is exceeded Includes Power source 10 ft. (3 m) MDX-100 MIG gun 13 ft. (4 m) cable electrode holder and 25 mm Dinse-style connector 10 ft. (3 m) work cable with clamp and 25 mm Dinse-style connector 6.5 ft. (2 m) power cord with MVP plugs for 120 V and 240 V Flow gauge regulator and gas hose for argon or AR/CO2 mix Hobart spool of .030 in. (0.8 mm) solid wire Two contact tips for .030 in. (0.8 mm) wire Quick Select drive roll for .024 in. (0.6 mm) or .030/.035 in. (0.8/0.9 mm) solid wire, and .030/.035 in. (0.8/0.9 mm) flux-cored wire Material thickness gauge 229895 Hook-and-loop cord wraps
This listing is for Each.
Read More >>

Miller Electric - 951000001 - Miller Multimatic 215 Single Phase CC/CV Multi-Process Welder With 120 - 240 Input Voltage, Welding Cart, Auto-Set Elite Technology And Accessory Package, ( Each )

  • Item #: 25919665
  • MFR SKU: 951000001
  • Trade Name: Multimatic® 215, Multimatic®
  • Input AC Voltage: 120 V, 240 V
  • Output Mode: CC/CV
  • Process: TIG (GTAW), Flux Cored (FCAW), MIG (GMAW), Stick (SMAW)
  • Output Voltage: 14 V, 23 V
  • Phase: Single Phase
  • Hz: 50/60 Hz
  • Amperage Range: 20 A, 230 A
  • Duty Cycle: CV: MIG/Flux-cored 120 V: 110 A At 19.5 V At 60% Duty Cycle, CC: TIG 240 V: 190 A At 17.6 V At 20% Duty Cycle, CC: TIG 120 V: 140 A At 15.6 V At 40% Duty Cycle, CV: MIG/Flux-cored 240 V: 150 A At 21.5 V At 40% Duty Cycle, CC: Stick 120 V: 90 A At 23.6 V At 40% Duty Cycle, CC: Stick 240 V: 190 A At 27.6 V At 20% Duty Cycle, CV: MIG/Flux-cored 240 V: 200 A At 24 V At 20% Duty Cycle
  • Weight: 38 lb
  • Output DC Amps Max: 230
