Marshall Engineered (MEPCO) - IB11-3-250 - Steam Trap: Cast Iron, 3/4 in FNPT, 765 lb/hr, 250 psi Max., 450F Max., Strainer Not Included

  • MFR SKU: IB11-3-250
  • ITEM #: 13174887
  • 12345
  • 0 Reviews / 0 Questions
$324.35
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 13174887
Standard inverted-bucket steam traps feature a reinforced metal body that can withstand the pressures and temperatures present in most hydronic heating systems.

Marshall Engineered (MEPCO) - IB11-3-250 - Steam Trap: Cast Iron, 3/4 in FNPT, 765 lb/hr, 250 psi Max., 450F Max., Strainer Not Included

  • Item #: 13174887
  • MFR SKU: IB11-3-250
  • Application: Blast Coils; Laundry; Steam Kettles; Water Heaters
  • Steam Trap Type: Inverted Bucket
  • Configuration: In-line
  • Body Material: Cast Iron
  • Float Material: Stainless Steel
  • Gasket Material: Non-Asbestos Fiber
  • Lever Assembly Material: Stainless Steel
  • Number of Ports: 2
  • Port Connection Size: 3/4 in
  • Port Connection Gender: Female
  • Port Connection Type: NPT
  • Max. Condensate Capacity: 765 lb/hr
  • Max. Operating Pressure: 250 psi
  • Allowable Temperature - Minimum: 35 ° F
  • Max. Operating Temperature : 450 ° F
  • Installation Orientation: Horizontal
  • Distance Between Inlet and Outlet Port: 5 in
  • Includes Strainer: Strainer Not Included
  • Includes Air Vent: Air Vent Included
  • Bolt Grade: Grade 5; Grade 7
  • Resistance Properties: Corrosion Resistant
  • Overall Length: 5 in
  • Overall Depth: 7 in
  • Manufacturer Series: IB
  • Manufacturer Part Number: IB11-3-250
  • Brand: MEPCO
  • UNSPSC: 40142503
  • Country of Origin: USA (subject to change)
