Littelfuse - THDB421A - THDB421A - SSAC Timer Delay-on-Break 120VAC 6A Ext Adjustable 1 100s 2x2

  • MFR SKU: THDB421A
  • ITEM #: 11429032
  • 12345
  • 0 Reviews / 0 Questions
$913.13
  • +
    -
Stock Status: SHIPS SOON(reserve your unit today)
Average lead time for this brand: 1-2 weeks. Specific products may vary.

ITEM #: 11429032
*** The Minimum Order Quantity of this Part is 10.
THDB421A - SSAC Timer Delay-on-Break 120VAC 6A Ext Adjustable 1 100s 2x2
The THDB Series Family
The THDB Series combines accurate timing circuitry with high power, solid-state switching. It can switch motors, lamps, and heaters directly without a contactor. You can reduce labor, component cost, and increase reliability with these small, easy-to-use, Digi-Power timers.
Operation (Delay-on-Break):
Input voltage must...
ITEM #: 11429032
*** The Minimum Order Quantity of this Part is 10.
THDB421A - SSAC Timer Delay-on-Break 120VAC 6A Ext Adjustable 1 100s 2x2
The THDB Series Family
The THDB Series combines accurate timing circuitry with high power, solid-state switching. It can switch motors, lamps, and heaters directly without a contactor. You can reduce labor, component cost, and increase reliability with these small, easy-to-use, Digi-Power timers.
Operation (Delay-on-Break):
Input voltage must be applied before and during timing. Upon closure of the initiate switch, the output energizes. The time delay begins when the initiate switch is opened. The output remains energized during timing. At the end of the time delay, the output de-energizes. The output energizes if the initiate switch is closed when input voltage is applied.
Reset: Reclosing the initiate switch during timing resets the time delay. Loss of input voltage resets the time delay and output.
Features :
  • High load currents up to 20A, 200A inrush
  • Fixed or adjustable 0.1s - 1000m in 6 ranges
  • ±0.5% repeat accuracy
  • ±1% factory calibration
  • 24, 120, or 230VAC
  • Metallized mounting surface for heat transfer
  • Totally solid-state & encapsulated

Auxiliary Products :
  • External adjust potentiometer:
    • P/N: P1004-95
    • P/N: P1004-95-X
  • Female quick connect:
    • P/N: P1015-13 (AWG 10/12)
    • P/N: P1015-64 (AWG 14/16)
  • Quick connect to screw adaptor: P/N: P1015-18
  • Versa-knob: P/N: P0700-7

This listing is for quantity 10" title="Quantity
