Leviton - 6050-C0W - Leviton 6050-C0W Cheetah Decora 4-Way Switch; 1-Pole, 120/277 Volt AC, 15 Amp, White

MFR SKU: 6050-C0W

ITEM #: 13297819

- 0 out of 5 stars
- 5 Star
  0 %
- 4 Star
  0 %
- 3 Star
  0 %
- 2 Star
  0 %
- 1 Star
  0 %
0 Reviews / 0 Questions

Currently Not In Stock

This product appears to have been discontinued, however, other similar products may be available. Our product specialists would be happy to research this for you and provide recommendations. Email me suggestions!

ITEM #: 13297819
Size: 1.770 Inch Width x 4.200 Inch Height
Quickwire or side wire for easy installation
Combination switches save space
Non-metallic strap for use with cheetah wallplates only
Max 30 deg C temperature rise at full-rated current after 50 cycles of OL at 150% rated current
Leviton Cheetah™ Decora® 4-Way Decora switch in white color is made of thermoplastic and features side wire and quick wire connection. At 150% rated current, switch has a maximum 30 deg C temp rise at full-rated current after 50 cycles of overload. Switch has a current rating of 15 Amps and voltage rating of 120/277 VAC. It withstands minimum of 1500 Volts and has an endurance of 50000 cycles minimum, resistive, inductive, tungsten filament lamp load. It features black, brass terminal ID and comes with copper conductor of size 10 - 14 AWG. It measures 1.770 Inch x 4.200 Inch and operates between -40 to 60 deg C temperature. It is ideal for residential applications and includes a non-metallic strap designed for use with Cheetah wall plates. It is certified for current interrupting at full rated current. It has V-2/UL94 flammability rating to withstand harsh environmental conditions. Non-grounding switch is CSA certified, UL listed and meets NEMA/ANSI standards.
15-Amp Decora Four Way Switch Cheetah, White

Leviton - 6050-C0W - Leviton 6050-C0W Cheetah Decora 4-Way Switch; 1-Pole, 120/277 Volt AC, 15 Amp, White

Item #: 13297819

MFR SKU: 6050-C0W

Technical Specs

Product Specification
Actuator Rocker
Amperage Rating 15
Application Commercial, Residential
Brand Leviton
Connection Side Wired; Quickwired
Contact Rating 120/277 VAC; 15 AMP
Environmental Conditions Flammability (Rated V-2)
Finish 2 White
00078477470596
Item Status O
Material Thermoplastic
Mounting Wallplate

Number Of Poles 1
Operating Cycles 50k
Operating Temperature -40 to +60
Ships Freight No
Ships Ground. Eligible for expedited shipping Yes
Size 4.20 H x 1.77 W
Special Features Quickwire or Side Wire for Easy Installation, Combination Switches Save Space, Non Grounding
Standard ETL Listed; UL20 and CSA Standards; NEMA;ANSI requirements; UL 20; CSA Certified ( 111)
Sub-Brand Decora; Cheetah
Type Combination
Voltage Rating 120/277
