Knobs

J.W. Winco GN6335.2 Star Knob, 1.26"(32), 1/4"-20, .47"(12), 3TCC5/E Star knobs GN 6335.2 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is made of steel to prevent edge breakages. Maximum heat resistance of nylon plastic: 110°C (230°F).Nylon plastic star knobs with stainless steel hub, see GN 6335.2- plastic star knobs with threaded stud, see GN 6335.4-TE. Special inch or metric bores, threads and assembled stud variations...

J.W. Winco GN6335.4-SG Star Knob, 32"(1.26), 20", 6335.4-SG-32-M6-20 Cast iron star knobs with male thread increase the range of clamping applications. Mainly used in clamping applications requiring heavier force and durability. Recommended when clamping with the hub face is necessary. Special inch and metric size threaded studs and stud lengths available upon request.

J.W. Winco 1.57" Diameter Plastic Hand Knob w/ 5/16"-18 Hole Size 0.91" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco GN5339.5 Triangular Knob, 1.61"(41), 1/2"-13, 8TCZ3/EMT GN 5339.5 stainless steel triangular knobs were specially designed for use on machinery in the food industry. The smooth and enclosed areas as well as the corner radii comply with the requirements of hygiene standards. With an elegant ergonomical design, these knobs also withstand a relatively high torque. Version with convex top and sides in highly polished finish available upon request in certain minimum quantities. Polished...

J.W. Winco 1.97" Diameter Plastic Hand Knob w/ 3/8"-16 Hole Size 0.98" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco 1.26" Diameter Plastic Hand Knob w/ 1/4"-20 Hole Size 1.46" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco GN5334 Hand Knob, .79"(20), 1/2"-13, 8TE17/E Refined and cost saving manufacturing techniques have made the hand knobs GN 5334 a very attractive and price worthy alternative in stainless steel.

J.W. Winco GN5336 Hand Knob, 70"(2.76), M16 x 2.0, 16NC53/EPO Hand knobs GN 5336 are forged; therefore, a close grain structure is maintained providing a high tensile strength and a smooth surface. Casting flash is eliminated through high quality production techniques. Special threads, bores or threaded studs in matte finish only, available upon request. Tapped through bore in inch and metric sizes in matte finish only available upon request.

J.W. Winco 1.26" Diameter Plastic Hand Knob w/ 1/4"-20 Hole Size 0.94" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco DIN6335-TP Star Knob, 1.97"(50), 3/8"-16, 6TJ03/K Nylon plastic hand knobs are an excellent choice for applications requiring higher shock resistance. Maximum heat resistance of nylon plastic: 110°C (230°F). Nylon plastic star knobs with threaded stud, GN 6335.4- ST.

J.W. Winco 0.98" Diameter Plastic Hand Knob w/ 1/4"-20 Hole Size 1.10" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco VPA Eight Lobed Knob, 35" (1.38) 35", 6302060 Maximum heat resistance of nylon plastic: 110°C (230°F). Plastic eight lobed knob with tapped insert, see VBA. Plastic eight lobed knob with tapped through insert, see VBA/FP.

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

J.W. Winco WN5335.5 Quick Release Nine Lobed Hand Knob, 3/8"-16, .394"(10), 6TFR7S Manufactured from solid stainless steel bar stock. Quick release knobs are used in such applications where the knob has to be completely removed after the releasing operation and refitted very rapidly for re-clamping. The knob is tilted over the threaded spindle. When in position, the knob is brought into a straight position for meshing of the two threads on knob and spindle. The knob will then have to be...

J.W. Winco DIN6335-TP Star Knob, 2.48"(63), 1/2"-13, 8TJ04/K Nylon plastic hand knobs are an excellent choice for applications requiring higher shock resistance. Maximum heat resistance of nylon plastic: 110°C (230°F). Nylon plastic star knobs with threaded stud, GN 6335.4- ST.

J.W. Winco GN6335.2 Star Knob, 1.97"(50), 3/8"-16, .71"(18), 6TCC7/E Star knobs GN 6335.2 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is made of steel to prevent edge breakages. Maximum heat resistance of nylon plastic: 110°C (230°F).Nylon plastic star knobs with stainless steel hub, see GN 6335.2- plastic star knobs with threaded stud, see GN 6335.4-TE. Special inch or metric bores, threads and assembled stud variations...

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

J.W. Winco GN6335.1 Star Knob, 80"(3.15), M16 x 2.0, 25"(.98), 16NC71/E Star knobs GN 6335.1 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is in steel to prevent edge breakages. Maximum heat resistance of phenolic plastic: 150°C (300°F).Nylon plastic, star knobs with threaded stud, see GN 6335.4- bores and threads larger than listed available upon request. Other modifications such as cross holes and set screw holes also available...

J.W. Winco 1.26" Diameter Plastic Hand Knob w/ 1/4"-20 Hole Size 0.71" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco 1.26" Diameter Plastic Hand Knob w/ 1/4"-20 Hole Size 1.21" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco DIN6336-TP Hand Knob, 50"(1.97), 16NXX5/K DIN 6336-TP nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Hand knobs with threaded stud, see GN 6336.4-ST. Maximum heat resistance of nylon plastic: 110°C 30°F).

J.W. Winco WN5335.5 Quick Release Nine Lobed Hand Knob, 1/2"-13, .512"(13) Manufactured from solid stainless steel bar stock. Quick release knobs are used in such applications where the knob has to be completely removed after the releasing operation and refitted very rapidly for re-clamping. The knob is tilted over the threaded spindle. When in position, the knob is brought into a straight position for meshing of the two threads on knob and spindle. The knob will then have to be turned...

J.W. Winco GN6336.5 Hand Knob, 32"(1.26), 55", 10N55E14/ST GN 6336.5 nylon plastic hand knobs with stainless steel studs are a first-rate choice for corrosion-free environments. Maximum heat resistance of nylon plastic: 110°C (230°F).

J.W. Winco VPA Eight Lobed Knob, 35" (1.38) 15", 6302047 Maximum heat resistance of nylon plastic: 110°C (230°F). Plastic eight lobed knob with tapped insert, see VBA. Plastic eight lobed knob with tapped through insert, see VBA/FP.

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

J.W. Winco GN6335.2 Star Knob, 2.48"(63), 1/2"-13, .79"(20), 8TCC8/E Star knobs GN 6335.2 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is made of steel to prevent edge breakages. Maximum heat resistance of nylon plastic: 110°C (230°F).Nylon plastic star knobs with stainless steel hub, see GN 6335.2- plastic star knobs with threaded stud, see GN 6335.4-TE. Special inch or metric bores, threads and assembled stud variations...

J.W. Winco EN5337.2 Five Lobed Knob, 1/4"-20, 1.26"(32), 3TAB2M/D Elesa original design technopolymer plastic five lobed knobs. The special type of technopolymer used and matte finish make this knob elegant and "soft" to touch. The operator obtains a strong clamping action without any discomfort due to its ergonomic design: five lobes, blended radius and well proportioned rim height assure a natural, safe and comfortable grip Resistant to solvents, oils, grease and other chemical...

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

J.W. Winco VPA Eight Lobed Knob, 25" (.98), 15", 6302020 Maximum heat resistance of nylon plastic: 110°C (230°F). Plastic eight lobed knob with tapped insert, see VBA. Plastic eight lobed knob with tapped through insert, see VBA/FP.

J.W. Winco 1.26" Diameter Plastic Hand Knob w/ 1/4"-20 Hole Size 0.63" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco GN5334 Hand Knob, 1.48"(37.5), 8T50E17 Refined and cost saving manufacturing techniques have made the hand knobs GN 5334 a very attractive and price worthy alternative in stainless steel.

J.W. Winco GN5339.5 Triangular Knob, 1.26"(32), 5/16"-18, 5TCZ2/EMT GN 5339.5 stainless steel triangular knobs were specially designed for use on machinery in the food industry. The smooth and enclosed areas as well as the corner radii comply with the requirements of hygiene standards. With an elegant ergonomical design, these knobs also withstand a relatively high torque. Version with convex top and sides in highly polished finish available upon request in certain minimum quantities....

J.W. Winco GN6336.4-SG Hand Knob, 21"(.83), 16" Hand knobs with male thread increase the range of application. For most applications the range of thread lengths is sufficient, however deviation in lengths, and other screw points, can be supplied. Special inch and metric studs lengths available upon request.

J.W. Winco GN5337.3 Safety Lobe Knob, .63", .71"(18), 1.18"(30), 5T16CN1K GN 5337.3 safety lobe knobs are best suited for applications where any unintended loosening of the knob may lead to accidents. In non-operative mode, the lobe knob is not engaged with the threaded stud; i.e., the knob can be turned easily. Only after axial pushing of the knob does the knob engage with the stud, so that it may be tightened or loosened. After release, the serrations disengage by means of a spring....

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

J.W. Winco GN6336.2 Hand Knob, 1.02"(26), .55"(14), 5/16"-18, 5TP93/E Hand knobs GN 6336.2 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is in steel to prevent edge breakages. The glass filled nylon plastic offers an advantage in price and can be delivered in various colors at certain minimum quantities. Maximum heat resistance of nylon plastic: 110°C (230°F). Phenolic plastic (Duroplast PF) hand knobs with steel hub,...

GN 6336.13 star knobs with loss protection can be attached to a base element with the help of a ball chain or a retaining cable. The star knobs are supplied ready assembled with retaining cable.

J.W. Winco GN6336.4-ST Hand Knob, 40"(1.57), 40" Hand knobs with male thread increase the range of application. Maximum heat resistance of nylon plastic: 110°C (230°F). Should clamping with the hand knob face be necessary, then it is recommended to use either GN 6336.4-TE plastic hand knob with steel hub or GN 6336.4-SG cast iron hand knob. Special shorter than listed stud lengths and various stud tips are available upon request.

J.W. Winco EN5337.5 Solid Five Lobed Knob, 0.75", 1/4"-20 Elesa original design technopolymer plastic solid five lobed knobs. This technopolymer knob has been designed for applications on machines and equipment whose parts, for health reasons, must be frequently cleaned, using water jets or steam. The five-lobed shape, which offers the fingers a secure grip, is solid, so that there are no cavities where unhealthy residues may be deposited. Resistant to solvents, oils, grease and other...

J.W. Winco GN6336.4-SK Hand Knob, 20"(.79), 40" Hand knobs with male thread increase the range of application. Special shorter than listed stud lengths and various stud tips are available upon request. Should clamping with the knob face be necessary, then it is recommended to use either GN 6336.4-TE phenolic plastic hand knob with steel hub or GN 6336.4-SG cast iron hand knob. Maximum heat resistance of phenolic plastic: 150°C (300°F).

J.W. Winco GN6335.4-SK Star Knob, 40"(1.57), 40", 6335.4-SK-40-M8-40 Star knobs with male thread increase the range of application. Should clamping with the hub face be necessary, then it is recommendable to use either GN 6335.4-TE or GN 6335.4-SG. Maximum heat resistance of phenolic plastic: 150°C (300°F).

J.W. Winco 1.57" Diameter Plastic Hand Knob w/ 5/16"-18 Hole Size 1.26" Hole Depth Nylon plastic hand knobs are an economical choice, yet offer top quality and ergonomic styling. Features Hand knob: Black matte glass filled nylon plasticTapped inserts: Zinc plated steel, molded-in

J.W. Winco GN6336.4-ST Hand Knob, 20"(.79), 25" Hand knobs with male thread increase the range of application. Maximum heat resistance of nylon plastic: 110°C (230°F). Should clamping with the hand knob face be necessary, then it is recommended to use either GN 6336.4-TE plastic hand knob with steel hub or GN 6336.4-SG cast iron hand knob. Special shorter than listed stud lengths and various stud tips are available upon request.

J.W. Winco Hand Knob, 16"(.63), 12"(.47), 6336.10-25-M5-25-MS GN 6336.10 nylon plastic hand knobs with stainless steel studs are an excellent choice for corrosion-free applications. The brass or plastic tip on the stud prevents indentations or other damage from occurring. Maximum heat resistance of nylon plastic: 110°C (230°F).

J.W. Winco CKS Four-Prong Clamping Knob, 1.5" (38.1), .38"(9.5) Lightweight yet long-lasting; these four-prong hand knobs made from a durable aluminum extrusion are an economical choice for a variety of equipment applications. Other modifications such as cross holes and set screw holes are available upon request.

J.W. Winco GN5339.5 Triangular Knob, 32"(1.26), M8 x 1.25, 8NCZ2/EMT GN 5339.5 stainless steel triangular knobs were specially designed for use on machinery in the food industry. The smooth and enclosed areas as well as the corner radii comply with the requirements of hygiene standards. With an elegant ergonomical design, these knobs also withstand a relatively high torque. Version with convex top and sides in highly polished finish available upon request in certain minimum quantities. Polished...

J.W. Winco CKS Four-Prong Clamping Knob, 2.0" (50.8), .50"(12.7) Lightweight yet long-lasting; these four-prong hand knobs made from a durable aluminum extrusion are an economical choice for a variety of equipment applications. Other modifications such as cross holes and set screw holes are available upon request.

J.W. Winco GN6335.2 Star Knob, 63"(2.48), M12 x 1.75, 20"(.79), 12NCC8/E Star knobs GN 6335.2 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is made of steel to prevent edge breakages. Maximum heat resistance of nylon plastic: 110°C (230°F).Nylon plastic star knobs with stainless steel hub, see GN 6335.2- plastic star knobs with threaded stud, see GN 6335.4-TE. Special inch or metric bores, threads and assembled stud variations...

J.W. Winco GN6335.1 Star Knob, 32"(1.26), M6 x 1.0, 12"(.47), 6NC67/E Star knobs GN 6335.1 with all steel hub have important advantages: The face of the hub is exactly square to the bore and is in steel to prevent edge breakages. Maximum heat resistance of phenolic plastic: 150°C (300°F).Nylon plastic, star knobs with threaded stud, see GN 6335.4- bores and threads larger than listed available upon request. Other modifications such as cross holes and set screw holes also available...

J.W. Winco DIN6335-TP Star Knob, 32"(1.26), M6 x 1.0, 6NJ01/K Nylon plastic hand knobs are an excellent choice for applications requiring higher shock resistance. Maximum heat resistance of nylon plastic: 110°C (230°F). Nylon plastic star knobs with threaded stud, GN 6335.4- ST.

J.W. Winco GN6336.3 Hand Knob, 42"(1.65), 13"(.51), M12 x 1.75 Quick release hand knobs GN 6336.3 are used in such applications where the knob has to be completely removed and refitted very rapidly for re-clamping. The knob is tilted over the threaded spindle. When in position, the knob is brought into a straight position for mating of the two threads on the insert and spindle. The hand knob will then have to be turned only by a fraction of a rotation to achieve clamping. Maximum heat...

J.W. Winco VBA Eight Lobed Knob, 55" (2.17), M8 x 1.25 An economical but durable hand knob for many applications. Maximum heat resistance of nylon plastic: 110°C (230°F). Plastic eight lobed knob with tapped through insert, see VBA/FP.. Plastic eight lobed knob with threaded stud, see VPA.

J.W. Winco V3/B/FP Three Lobed Knob, 18"(.71), 7384005 Resistant to solvents, oils, grease and other chemical agents. Maximum heat resistance of nylon plastic: 110°C (230°F). Stainless steel inserts available upon request. Three lobed thermoplastic knob with tapped blind hole, see V3/B/P; with threaded stud, see V3/B.

J.W. Winco FSK Five Lobed Knob, 2.25" (57.2) Heat resistance of nylon plastic: Maximum heat resistance 230° F (110° C) Approximate melting point 446° F (230° C) Additional thread sizes also available upon request.

J.W. Winco GN5339.5 Triangular Knob, 21"(.83), M5 x .8, 5NCZ0/EMT GN 5339.5 stainless steel triangular knobs were specially designed for use on machinery in the food industry. The smooth and enclosed areas as well as the corner radii comply with the requirements of hygiene standards. With an elegant ergonomical design, these knobs also withstand a relatively high torque. Version with convex top and sides in highly polished finish available upon request in certain minimum quantities. Polished...

J.W. Winco GN6336.3 Hand Knob, 34"(1.34), 10.5"(.41), M10 x 1.5 Quick release hand knobs GN 6336.3 are used in such applications where the knob has to be completely removed and refitted very rapidly for re-clamping. The knob is tilted over the threaded spindle. When in position, the knob is brought into a straight position for mating of the two threads on the insert and spindle. The hand knob will then have to be turned only by a fraction of a rotation to achieve clamping. Maximum heat...

J.W. Winco CKS Four-Prong Clamping Knob, 3", 3.0" (76.2), 1.25"(31.8) Lightweight yet long-lasting; these four-prong hand knobs made from a durable aluminum extrusion are an economical choice for a variety of equipment applications. Other modifications such as cross holes and set screw holes are available upon request.

J.W. Winco CKS Four-Prong Clamping Knob, 1.5" (38.1), .88"(22.4) Lightweight yet long-lasting; these four-prong hand knobs made from a durable aluminum extrusion are an economical choice for a variety of equipment applications. Other modifications such as cross holes and set screw holes are available upon request.

J.W. Winco EN5337.2 Five Lobed Knob, 5/16"-18, 1.57"(40), 5TAB3M/E Elesa original design technopolymer plastic five lobed knobs. The special type of technopolymer used and matte finish make this knob elegant and "soft" to touch. The operator obtains a strong clamping action without any discomfort due to its ergonomic design: five lobes, blended radius and well proportioned rim height assure a natural, safe and comfortable grip Resistant to solvents, oils, grease and other chemical...

J.W. Winco DIN6335-CI Star Knob, 3.15"(80), 5/8"-11, .98"(25), 10TC58/E Star knobs with threaded stud, see GN 6335.4-SG. Plain and threaded through bores in both inch and metric sizes are available upon request. Special inch or metric bores and threads available upon request.

J.W. Winco GN6336.4-ST Hand Knob, 20"(.79), 30" Hand knobs with male thread increase the range of application. Maximum heat resistance of nylon plastic: 110°C (230°F). Should clamping with the hand knob face be necessary, then it is recommended to use either GN 6336.4-TE plastic hand knob with steel hub or GN 6336.4-SG cast iron hand knob. Special shorter than listed stud lengths and various stud tips are available upon request.

J.W. Winco Hand Knob, 20"(.79), 14"(.55), 6336.10-32-M6-20-KU GN 6336.10 nylon plastic hand knobs with stainless steel studs are an excellent choice for corrosion-free applications. The brass or plastic tip on the stud prevents indentations or other damage from occurring. Maximum heat resistance of nylon plastic: 110°C (230°F).

J.W. Winco VPA Eight Lobed Knob, 25" (.98), 25", 6302040 Maximum heat resistance of nylon plastic: 110°C (230°F). Plastic eight lobed knob with tapped insert, see VBA. Plastic eight lobed knob with tapped through insert, see VBA/FP.
