057455 - Discovery Kit, Heat Pipe, 147 PieceThis listing is for Each.
Product Overview The LA 17/200 24V is a 200mm 230VAC/24VDC fan-cooled Heat Sink with raw degreased aluminium, axial fan, surface mounting, 0.085 to 0.05K/W thermal resistance and without airflow chamber. This heat sink features Papst, ball bearing, extremely low losses due to optimised hollow fin geometry, effective heat dissipation, compact construction, two opposite mounting surfaces are milled flat.11W Power input4400RPM Speed rating-30 to 55°C Temperature range Applications HVAC WARNING:...
Product Overview Latest generation extrusion technologyExceptional fin height/space ratioIncreased thermal performance from a lower massOptimum performance achieved when force air cooled0.07°C/WThis listing is for Each.
Product Overview The 144-2 is a Compression Mounting Clamp Assembly for semiconductors to 4-inch (101.6mm) diameter. The 144 series clamp systems provide electrical and industrial equipment manufacturers with complete system solutions for proper installation and heat dissipation for high-power compression pack semiconductor. The high-quality mounting clamp assemblies are the worldwide standard for mounting, compression and clamping press-pack SCR, thyristor, rectifier and other high power disc packaged...
Product Overview The 416601U00000G from Aavid Thermalloy is Hi-Contact liquid cold plate. This cold plate is designed for engineers seeking a cost effective solution for medium power density applications. The 416601U00000G feature a interlocking groove and tube geometry that improves mechanical robustness and thermal performance over conventional designs. Tube directly contacts the base of the device cooled improving thermal resistance. Thin epoxy joint between tube and plate outperforms ‘dry’...
Product Overview Less flow lossThermally efficientCompact designFailure rate: >70000h @40°C WARNING: Cancer and Reproductive Harm - . This listing is for Each.
Product Overview The LA 7/150 24V is a 150mm 230VAC/24VDC fan-cooled Heat Sink with raw degreased aluminum, axial fan, screw mounting, 0.11 to 0.05K/W thermal resistance. This heat sink features Papst, ball bearing, geometry of hollow fin optimizing the air flow, particularly effective heat dissipation, compact construction, semiconductor mounting surface for milled flat.3.4W Power input6400RPM Speed rating-20 to 65°C Temperature range Applications HVAC WARNING: Cancer and Reproductive Harm...
Product Overview Latest generation extrusion technologyExceptional fin height/space ratioIncreased thermal performance from a lower massOptimum performance achieved when force air cooled0.08°C/WThis listing is for Each.
120457 - Heat Sink, 304.8 mmThis listing is for Each.
Product Overview The 193AB1500B is a 150 x 240 x 46mm Heat Sink made of aluminium with anodized finish and features vertical mount. Applications Industrial This listing is for Each.
Product Overview Latest generation extrusion technologyExceptional fin height/space ratioIncreased thermal performance from a lower massOptimum performance achieved when force air cooled0.04°C/WThis listing is for Each.
Product Overview The 392-120AB is a 120 x 125 x 135.8mm high performance Heat Sink made of aluminum with black anodized finish. This extruded heat sink is designed for effective cooling of single and multiple isolated power modules, IGBTs, relays and rectifiers. Features standardized 80mm mounting in both natural and forced convection. Applications IndustrialThis listing is for Each.
Product Overview The 395-2AB is a Heat Sink made of aluminum with black anodized finish at 50°C rise above ambient temperature. This performance/low profile heat sink is suitable for use with power modules and IGBTs. Applications IndustrialThis listing is for Each.
Product Overview The CP4A-114A-108E is a Cold Plate Four-pass Heat Sink with aluminum 6063-T5 plate and 0.375-inch OD nominal wall thickness of 0.05-inch copper tubing. This PCB heat sink design flexibility chill plate lengths can be configured as well as mounting hole patterns to accept a multitude of devices. It features thermal efficient design, exposed copper tubing on the mounting surface for the most efficient heat transfer. The CP series also provides maximum heat removal for SCRs, rectifiers,...
HSF-50-19-Y-F - Fan / Force Cooled Heat Sink, 1.31 °C/W, 18.5 mm, 50 mm, 50 mm, 5.9 /min, 29 dBAThis listing is for Each.
Product Overview The 394-2AB is a 139.7 x 38.1 x 127mm low-profile Heat Sink made of aluminum with black anodized finish. This extruded heat sink is designed for power modules and IGBTs and features 101 x 139mm base mounting area with 6 mounting holes. Applications IndustrialThis listing is for Each.
Product Overview The 392-300AB is a 300 x 125 x 135.8mm high performance Heat Sink made of aluminum with black anodized finish. This extruded heat sink is designed for effective cooling of single and multiple isolated power modules, IGBTs, relays and rectifiers. Features standardized 80mm mounting in both natural and forced convection. Applications Industrial This listing is for Each.
120456 - Heat Sink, 152.4 mmThis listing is for Each.
HSF-48-19-Y-F - Fan / Force Cooled Heat Sink, 1.41 °C/W, 18.5 mm, 47.5 mm, 47.5 mm, 5.9 /min, 29 dBAThis listing is for Each.
HSF-48-28-B-F - Fan / Force Cooled Heat Sink, 0.88 °C/W, 27.5 mm, 47.5 mm, 47.5 mm, 5.9 /min, 29 dBA This listing is for Each.
AH12310V06000GE - Heat Sink, 0.93 °C/W, 104.78 mm, 44.45 mm, 152.4 mmThis listing is for Each.
HSF-48-30-Y-F - Fan / Force Cooled Heat Sink, 0.83 °C/W, 29.5 mm, 47.5 mm, 47.5 mm, 5.9 /min, 29 dBAThis listing is for Each.
Product Overview The 394-1AB is a 76.2 x 38.1 x 127mm low-profile Heat Sink made of aluminum with black anodized finish. This extruded heat sink is designed for power modules and IGBTs and features 101 x 76mm base mounting area with 4 mounting holes. Applications IndustrialThis listing is for Each.
Product Overview The 130-C is a Compression Mounting Clamp Assembly for semiconductors to 2.25-inch (57.2mm) diameter. The 130 series clamp systems provide electrical and industrial equipment manufacturers with complete system solutions for proper installation and heat dissipation for high-power compression pack semiconductor. The high-quality mounting clamp assemblies are the worldwide standard for mounting, compression and clamping press-pack SCR, thyristor, rectifier and other high power disc...
Product Overview The LA 10/150 24V is a 150mm 230VAC/24VDC fan-cooled Heat Sink with raw degreased aluminum, axial fan, surface mounting, 0.182 to 0.055K/W thermal resistance. This heat sink features Papst, ball bearing, geometry of hollow fin optimizing the air flow, particularly effective heat dissipation, compact construction, semiconductor mounting surface for milled flat.6W Power input5000RPM Speed rating-20 to 75°C Temperature range Applications HVAC WARNING: Cancer and Reproductive Harm...
HSF-50-22-B-F - Fan / Force Cooled Heat Sink, 1.06 °C/W, 21.5 mm, 50 mm, 50 mm, 5.9 /min, 29 dBAThis listing is for Each.
HSF-50-40-Y-F - Fan / Force Cooled Heat Sink, 0.67 °C/W, 39.5 mm, 50 mm, 50 mm, 5.9 /min, 29 dBAThis listing is for Each.
Product Overview The 173AB3000B is a Heat Sink made of aluminum with anodized finish. It features that two sections may be assembled fin-to-fin, providing a highly efficient force cooled assembly. Applications IndustrialThis listing is for Each.
CMBF0135352901-00 - Fan / Force Cooled Heat Sink, BGA, Chip Set, 35 mm, 35 mm RoHS Compliant: YesThis listing is for Each.
Product Overview The 193AB2500B is a Heat Sink made of aluminum. The thermal resistance is calculated based on a distributed heat load on anodized heat sink with vertically mounted fins based on a 60°C temperature rise. Applications IndustrialThis listing is for Each.
Product Overview The 97CN-02000-A-200 is a 200 x 200 x 40mm extruded range-4 Heat Sink made of aluminium with black anodized surface. This heat sink features 2 x 3.75mm diameter extruded holes, 70.5mm slot spacing long the base. Applications Defence, Military & Aerospace This listing is for Each.
Product Overview The 938SP-01500-A-200 is a 150 x 160 x 40mm extruded range-4 Heat Sink made of aluminium with black anodized surface. This heat sink features 2 x 3.75mm diameter extruded holes, 70.5mm slot spacing long the base. Applications Defence, Military & AerospaceThis listing is for Each.
Product Overview The 96CN-03000-A-200 is a 300mm extruded Heat Sink with aluminium, 0.53°C/W thermal resistance. This heat sink features high power extrusions. Applications HVACThis listing is for Each.
Product Overview The LA ICK 17 X17 W 12V is an active Heat Sink with universal fan cooler, made of aluminium with black anodised finish. It is suitable for use with universal processors and offers thermal conductive adhesive way of fixation. It is specially adapted to industrial environment and its performance is designed for reliability and a long lifespan. The fan is burn-in tested and made for a long maintenance-free lifespan.Integrated retaining spring fixes the fan cooler safely on the ICEasy...
Product Overview The THFU 3 is a 20.5 x 10mm Retaining-spring Clip for use with TO-218, TO-220, TO-247 and TO-264 transistors. Applications Industrial WARNING: Cancer and Reproductive Harm - .This listing is for Each.
Product Overview The 056325 is a Heat Pipe Exploration Kit is perfect for interaction and education in any design lab or engineering environment and they are to get hands onto heat pipes and get a feel for how they work, what they do.5 to 15W Power range for 4mm pipe diameter25 to 45W Power range for 6mm pipe diameter35 to 60W Power range for 8mm pipe diameter Applications Industrial Contents 30 Heat pipes (228.6mm), 30 Heat pipes (304.8mm), 30 Heat pipes (153.4mm), 15 Condenser plates (40 x 150mm),...
SKV606021-CU - Heat Sink, 7.2 °C/W, 60 mm, 21 mm, 60 mmThis listing is for Each.
Product Overview The 637-10ABPE is a 12.7mm high-efficiency board level power semiconductor Heat Sink with aluminum, black anodized, 12.67°C/W thermal resistance. This heat sink features wave-solderable pins on 1-inch centers for vertical mounting on printed circuit boards. Use this heat sink where weight and board space occupied is minimized. Applications HVACThis listing is for Each.
MAX07NG - Heatsink Clip, 12 mm Width, For TO-220 Packages, Max Clip SeriesThis listing is for Each.
Product Overview The 510AB0500MB(TO3) is a 50mm Heat Sink with aluminium construction, natural and black anodized finish, 3.3°C/W thermal resistance. Applications HVACThis listing is for Each.
Product Overview The CEBF0127271803-00 is a 27mm BGA Cooler with aluminium construction, black anodized finish, Vapo bearing, clip-on mounting, 3.62°C/W thermal resistance. It features extrusion technology and used for 27 x 27mm chip set.1.7mm Thickness15000RPM Speed5VDC Voltage0.09A Current Applications HVACThis listing is for Each.
Product Overview The 4597 is a 21 x 14.5mm Heat Sink Clip with zinc high resistance plated finish and features vertical/horizontal mount orientation.50h Neutral salt corrosion resistance Applications Industrial, Consumer Electronics WARNING: Cancer and Reproductive Harm - .This listing is for Each.
Product Overview Heatsink especially for SMD packagesLow profileReduced weightEffective heat dissipationCan be gluded directly to component WARNING: Cancer and Reproductive Harm - .This listing is for Each.
Product Overview The 4880G is a Thermalfilm Mounting Kit for use with TO-220 devices. Applications Industrial Contents Insulator thermal film, Shoulder washer, #4 Flat washer, #4-40 UNC-2B Hex nut, #4-40 UNC-2A X 1/2 Long Phillips pan head screw, #4 Lock washer.This listing is for Each.
Product Overview The 6400BG is a 25.4mm high-power extruded Heat Sink with aluminum, black anodized, large radial fins and straight pins, 2.7 thermal resistance.Vertical mount orientationQuality Extruded designPCB Pins for secure mounting Applications HVACThis listing is for Each.
Product Overview The 43DN-01000-A-200 is a 100 x 100 x 40mm extruded range-2 Heat Sink made of aluminium with black anodized surface. This heat sink features 2 x 3.75mm diameter extruded holes, 70.5mm slot spacing long the base. Applications Defence, Military & AerospaceThis listing is for Each.
Product Overview The 890SP-01000-A-100 from H S Marston is a surface mount high density cooling Ultra-Fin. This Ultra-Fin is developed in extrusion technology allows a much higher fin height to fin spacing ratio. Ultra-Fin provides much greater performance in a force cooled environment that has hitherto been possible with standard extrusions.Improved system performanceCost effectiveFin length of 100mmFin height of 32mmThermal resistance of 0.12°C/WAluminium heat sink Applications Industrial...
PV-T22-38E - Heat Sink, 3.89 °C/W, TO-220, TO-247, TO-264, 38.6 mm, 17.5 mm, 51.1 mm This listing is for Each.
Product Overview The ICK SMD C 17 SA is a 30 x 7.5 x 17mm Heat Sink made of aluminium with black anodized surface. This heat sink is suitable for DIL-IC, PLCC and SMD components.2.8mm Plate thickness Applications Industrial WARNING: Cancer and Reproductive Harm - .This listing is for Each.
Product Overview The CLP-212G is a 10 x 0.5mm Cover Over Edge Clip for use with TO-220 devices. Applications Industrial, Consumer ElectronicsThis listing is for Each.
Product Overview The 529702B02500G is an extruded Heat Sink with large radial fins and solderable pins suitable for TO-220 and single-gauge (0.02-inch) TO-220 packages. It is made of aluminium with black anodize finish. This non-electronic component is functionally unaffected by the normal soldering or reflow processes used for semiconductor circuits. The heat resistance time or heat resistance temperature is not applicable for the component.Vertical mount orientation Applications HVAC, Thermal...
Product Overview The 529802B02500G is a Heat Sink made of aluminum with black anodized finish. This PCB extruded heat sink comes with large radial fins and solderable pins. This non-electronic component is functionally unaffected by the normal soldering or reflow processes used for semiconductor circuits. The heat resistance time or heat resistance temperature is not applicable for the component. It features vertical mounting orientation. It is suitable for use with TO-220 devices. Applications...
Product Overview The 6021BG is a channel Heat Sink with straight fins and integrated tabs suitable for TO-220 and single-gauge (0.02-inch) TO-220 packages. It is made of aluminium with black anodize finish.Vertical mount orientation Applications HVAC, Thermal ManagementThis listing is for Each.
Product Overview The 6237BG is a Heat Sink with of aluminum with black anodized finish. This PCB hat section style heat sink features an integrated clip and vertical mounting orientation. It is suitable for use with TO-220 devices. Applications IndustrialThis listing is for Each.
7020B-MTG - Heat Sink, Square, PCB, Channel, 8.7 °C/W, TO-220, 33.02 mm, 35.83 mm, 11.94 mm This listing is for Each.
534202B02853G - Heat Sink, Square, PCB, Channel, 13.4 °C/W, TO-220, 25.4 mm, 29.97 mm, 12.7 mmThis listing is for Each.
Product Overview The 401K is a double-surface Heat Sink made of aluminium alloy with black anodized finish for high-power TO-3 case styles. With fins oriented vertically in cabinet sidewall applications it is recommended for critical space applications where maximum heat dissipation is required. Forced convection performance is also exemplary with these double surface fin types. Semiconductor mounting hole style "F" offers a single centred 0.27-inch diameter mounting hole (with a 0.75-inch...
Product Overview The 660-29AB is an unidirectional fin Heat Sink made of aluminium with black anodized finish for BGA. Applications HVAC, Thermal ManagementThis listing is for Each.
Product Overview The 274-1AB is a 9.5 x 13.2 x 19.1mm low-height wave solderable channel-style Heat Sink made of aluminium with black anodized finish. This board level heat sink features vertical/horizontal mount orientation and mounting can be through mounting hole. This heat sink is suitable for use with TO-220 device. Applications IndustrialThis listing is for Each.
Product Overview The MPC101002T is a 10 is a low-profile, light-weight, flat Micro-Porous Ceramic Heat Sink (MPCHS). Due to its highly micro-porous nature it provides a very large surface area compared to conventional copper/aluminium heatsinks and therefore provides excellent heat dissipation without storing heat within its self. The MPCHS also has the lowest thermal capacity of unit volume compared to copper and aluminium heat sinks. Supplied with thermal adhesive tape as standard, without adhesive...
Product Overview The 230-75AB is a Heat Sink made of aluminum with black anodized finish. This compact, wavesolderable low-profile self-locking board level power semiconductor heat sink features clip/mounting hole vertical/horizontal mounting orientation. It is suitable for use with TO-220 devices. Applications IndustrialThis listing is for Each.
Product Overview The 150CN-01250-A-200 is a 125mm extruded Heat Sink with aluminum, matt black anodized, 1°C/W thermal resistance. This heat sink features high power extrusions. Applications HVACThis listing is for Each.
Product Overview The DB120-20 is a square Heat Sink made of aluminium with black anodize finish. Applications HVAC, Thermal ManagementThis listing is for Each.
Product Overview The 504102B00000G is an narrow base channel Heat Sink for use with TO-220 and single-gauge (0.020-inch) TO-220 packages. This 6270B heat sink is made of aluminium with black anodize finish.Vertical and horizontal mount orientation Applications HVAC, Thermal ManagementThis listing is for Each.
