Image is an illustration, may not reflect the exact product sold.


Other products by Hach

Hach - D3726E2T - Digital Electrodeless Conductivity Sensor, Convertible Body Style, PVDF Body Material, Digital Gateway, 1m Extension Cable

  • MFR SKU: D3726E2T
  • ITEM #: 10447328
  • 12345
  • 0 Reviews / 0 Questions
$1,857.25
  • +
    -
Stock Status: SHIPS SOON(reserve your unit today)
Average lead time for this brand: 1-2 weeks. Specific products may vary.

ITEM #: 10447328
PVDF , Convertible Mounting Style , 6m (20 ft) Analog Cable , Electrodeless Conductivity Sensor , includes 6120800 Digital Gateway for Connecting to sc Controller and a 6122400 1m (3 ft) Digital Extension Cable
  • Wide Measuring Range
  • Low Maintenance Design
  • Versatile Mounting Styles
  • Principal of Operation
  • Withstands Harsh Environments

Hach - D3726E2T - Digital Electrodeless Conductivity Sensor, Convertible Body Style, PVDF Body Material, Digital Gateway, 1m Extension Cable

  • Item #: 10447328
  • MFR SKU: D3726E2T
  • Wide Measuring Range
  • A built-in Pt 1000 RTD compensates the measured conductivity for changes in process temperature. Low Maintenance Design
  • The inductive sensor design eliminates polarization and electrode coating problems that commonly affect conventional contacting electrode-type conductivity sensors. Versatile Mounting Styles
  • Sensors can be installed using a choice of four mounting styles\xe2\x80\x94immersion , insertion , union , and sanitary. Principal of Operation
  • Inductive conductivity sensors induce a low current in a closed loop of solution , then measure the magnitude of this current to determine the solution\xe2\x80\x99s conductivity. The conductivity analyzer drives Toroid A , inducing an alternating current in the solution. This current signal flows in a closed loop through the sensor bore and surrounding solution. Toroid B senses the magnitude of the induced current which is proportional to the conductance of the solution. The analyzer processes this signal and displays the corresponding reading. Withstands Harsh Environments
  • The inductive sensor is available in sanitary (CIP) flange style and convertible styles in PFA\xc2\xae , polypropylene , PEEK\xc2\xae , and PVDF material. Select sensors can withstand high pressures and temperatures. What's included?
  • Includes: sensor with cable , digital gateway , extension cable and manual
  • Accuracy: \xc2\xb1 0.01 % of reading , all ranges
  • Body Material: PVDF
  • Cable Length: 22 ft
  • Flow: Rate 3 m (10 ft.) per second , maximum
  • Material: PVDF
  • Mounting: Convertible
  • Operating Temperature Range: -10 - 200 \xc2\xb0C
  • Range: 200 \xc2\xb5S/cm - 2000 mS/cm
  • Region: Global
  • Sensor Cable: Polypropylene and PVDF Sensors: 5 conductor (plus two isolated shields) cable with XLPE (cross-linked polyethylene) jacket; rated to 150 \xc2\xb0C (302\xc2\xbaF); 6 m (20 ft.) long
  • Sensor Type: Digital
  • Temperature Sensor: Temperature Compensator Pt 1000 RTD
  • Warranty: 12 months
  • Wetted Materials: Polypropylene , PVDF , PEEK\xc2\xae or PFA\xc2\xae
  • What's included?: Includes: sensor with cable , digital gateway , extension cable and manual
  • Includes: sensor with cable , digital gateway , extension cable and manual
