Erie - VT3343G13B020 - Zone Valve Body Assembly

  • MFR SKU: VT3343G13B020
  • ITEM #: 20635955
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $251.22 You Save: $145.27
57.83 % OFF
$105.95
  • +
    -
Stock Status: SHIPS SOON(reserve your unit today)

ITEM #: 20635955
ERIVT3343G13B020 120v 3/4" Inverted Flair 3-way Zone Valve 3.5cv Nc 18" Lead Wires Replaces 0647c0309gb00 0647c0329hb00

Erie - VT3343G13B020 - Zone Valve Body Assembly

  • Item #: 20635955
  • MFR SKU: VT3343G13B020
  • Zone Valve Body Assembly Type 3-Way Nominal Size 3/4 Inch End Connection Inverted Flare x Inverted Flare Actuation Type 2-Position, Spring Return, On/Off (General Close-Off) Valve Position Normally Closed Body Material Forged Brass Valve Timing 25 Second for 60 Hertz/30 Second for 50 Hertz/9 Second for Spring Return (Full Open to Full Close) Mounting Type Horizontal/Vertical Input Supply Rating 110/120 Volt AC at 60/50 Hertz Temperature Rating 32 to 200 Deg F (Fluid) Pressure Rating 60 PSI (Close-Off), 300 PSI (Static) Media Handled Hot/Chilled Water, Glycol Inclusions/Features Hysteresis Synchronous Motor for Long Life, Spring Return Operation Provides a Fail-Safe, Manual Override Lever Application Heating and Cooling Applicable Standard ANSI Class IV Flow Capacity 4 Cv Electrical Connection 18 Inch Lead Material Nickel Plated Brass (Stem), Brass (Seat) Buna N (Paddle) Ambient Temperature 104 Deg F Humidity Range 5 to 95 Percent (Non-Condensing) Features / Benefits Direct Replacement for All Existing 2-Position Pop-Top Applications Hysteresis Synchronous Motor for Long Life Spring Return Operation Provides a Fail Safe Valve Body Rated for 300 PSI Static Pressure Actuator Mounts Directly onto Valve Body without Need for Linkages or Calibration Manual Override Lever (Normally Closed Only) Actuator Can be Replaced without any Tools or Removal of Valve from System
