Eaton Electrical - A25CGE40T - EATON Definite Purpose Magnetic Motor Starter: Non-Reversing, 3 Poles, 40 A, 24V AC Coil, Thermal

  • MFR SKU: A25CGE40T
  • ITEM #: 4902839
  • 12345
  • 0 Reviews / 0 Questions
$968.59
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)
Average lead time for this brand: 1-2 weeks. Specific products may vary.

ITEM #: 4902839
These non-reversing definite-purpose motor starters with thermal overloads have enclosures that protect their internal components from impacts, debris, and dust. Non-reversing motor starters connect and disconnect power to motors and other high-current equipment and machinery in a single direction. Thermal overloads, also known as heaters, prompt motor starters to break electrical connections with downstream equipment once a set temperature is reached to protect connected loads from overheating...
ITEM #: 4902839
These non-reversing definite-purpose motor starters with thermal overloads have enclosures that protect their internal components from impacts, debris, and dust. Non-reversing motor starters connect and disconnect power to motors and other high-current equipment and machinery in a single direction. Thermal overloads, also known as heaters, prompt motor starters to break electrical connections with downstream equipment once a set temperature is reached to protect connected loads from overheating and causing damage. They contain either bimetallic strips or melting alloy solder materials. When the current exceeds a predetermined threshold and temperatures rise, the material bends or liquefies, causing the thermal unit to break the circuit and cause the motor starter to break its power contacts. As the materials cool down, they will return to their normally closed position and the circuit can be reset automatically or manually.
Read More >>

Eaton Electrical - A25CGE40T - EATON Definite Purpose Magnetic Motor Starter: Non-Reversing, 3 Poles, 40 A, 24V AC Coil, Thermal

  • Item #: 4902839
  • MFR SKU: A25CGE40T
  • Brand: EATON
  • Manufacturer Part Number: A25CGE40T
  • Series: A25
  • Overload Protection Type: Thermal
  • Thermal Units Required: 3 Thermal Units Required (Not Included)
  • Reversing Capability: Non-Reversing
  • Number of Poles: 3
  • Phase: Three
  • Max Current (AC): 40 A
  • Coil Voltage: 24V AC
  • Frequency: 50/60 Hz
  • Nominal Coil Voltage @ 60Hz: 24V AC
  • Horsepower @ Single Phase - 120V AC: 3 hp
  • Horsepower @ Single Phase - 240V AC: 7-1/2 hp
  • Horsepower @ Three Phase - 240V AC: 10 hp
  • Horsepower @ Three Phase - 480V AC: 20 hp
  • Horsepower @ Three Phase - 600V AC: 20 hp
  • Locked Rotor Load: 160 A @ 575V AC; 200 A @ 460V AC; 240 A @ 115V AC; 240 A @ 230V AC
  • Wire Termination Type: Screw
  • NEMA Enclosure Rating: 1
  • IP Rating: IP20
  • Overall Height: 12.6 in
  • Overall Width: 6 in
  • Overall Depth: 7.62 in
  • Mounting Hole Distance - Height: 10.39 in
  • Mounting Hole Distance - Width: 6 in
  • Minimum Operating Temperature: -13 ° F
  • Maximum Operating Temperature: 149 ° F
  • Standards: CSA; UL Listed
  • UNSPSC: 39121521
  • Country of Origin: USA (subject to change)
