Congress Drives - VP350X050 - CONGRESS Variable Pitch V-Belt Pulley: 1 Groove, 3.25 in Outside Dia, 1/2 in Bore Dia, Zinc, Plain

  • MFR SKU: VP350X050
  • ITEM #: 4854750
  • 12345
  • 0 Reviews / 0 Questions
$37.95
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 4854750
Fixed-bore die-cast variable-pitch V-belt pulleys have a finished bore, or center hole, that is machined to a set diameter to insert a shaft of the same size. They are ready to install with machined keyways and/or set screws to secure the shaft and prevent slipping. These zinc die-cast pulleys are non-corrosive, lightweight, impact-resistant, and non-toxic. They are suitable for light duty applications such as fans and blowers in HVAC applications.

Congress Drives - VP350X050 - CONGRESS Variable Pitch V-Belt Pulley: 1 Groove, 3.25 in Outside Dia, 1/2 in Bore Dia, Zinc, Plain

  • Item #: 4854750
  • MFR SKU: VP350X050
  • Brand: CONGRESS
  • Manufacturer Part Number: VP350X050
  • 3L Pitch Diameter (Maximum): 2.9 in
  • 3L Pitch Diameter (Minimum): 2.1 in
  • 4L Pitch Diameter (Maximum): 3.4 in
  • 4L Pitch Diameter (Minimum): 2.4 in
  • 5L Pitch Diameter (Maximum): 3.5 in
  • 5L Pitch Diameter (Minimum): 2.9 in
  • A Pitch Diameter (Maximum): 3.4 in
  • A Pitch Diameter (Minimum): 2.4 in
  • AX Pitch Diameter (Maximum): 3.4 in
  • AX Pitch Diameter (Minimum): 2.4 in
  • B Pitch Diameter (Maximum): 3.5 in
  • B Pitch Diameter (Minimum): 2.9 in
  • BX Pitch Diameter (Maximum): 3.5 in
  • BX Pitch Diameter (Minimum): 2.9 in
  • Bore Diameter: 1/2 in
  • For Belt Section:
  • 3L
  • 4L
  • 5L
  • A
  • B
  • For V-Belt Type: Classical
  • Includes: Set Screw
  • Keyway: No
  • Length Through Bore: 1-1/8 in
  • Material: Zinc
  • Material Fabrication: Cast
  • Material Grade: Zamak 3
  • Maximum Face Width: 0.781 in
  • Maximum Pitch Diameter:
  • 2.90 in (3L)
  • 3.40 in (4L)
  • 3.50 in (5L)
  • Minimum Face Width: 0.469 in
  • Minimum Pitch Diameter:
  • 2.10 in (3L)
  • 2.40 in (4L)
  • 2.90 in (5L)
  • Number of Grooves: 1
  • Outside Diameter: 3.25 in
  • Pulley Construction: Plain
  • Set Screw Size: 5/16 in
  • Weight: 0.99 lb
  • UNSPSC: 31171804
  • Country of Origin: USA (subject to change)
