CommScope / Amphenol - DB420-B - Andrew Omni Exposed Dipole Antenna, 450-470 MHz, 360 deg. Horizontal Beamwidth, Fixed Electrical Tilt

  • MFR SKU: DB420-B
  • ITEM #: 3225973
  • 12345
  • 0 Reviews / 0 Questions
$5,865.38
  • +
    -
  • Saw It For Less?
Stock Status: Low Stock

ITEM #: 3225973
Specifications
General Specifications

Antenna Type Omni
Band Single band
Color Silver
Grounding Type RF connector inner conductor and body grounded to reflector and mounting bracket
Performance Note Outdoor usage
Radiator Material Aluminum
RF Connector Interface N Male
RF Connector Location End of flexible lead
RF Connector Quantity, low band 1
RF Connector Quantity, total 1
Dimensions
...
ITEM #: 3225973
Specifications
General Specifications

Antenna Type Omni
Band Single band
Color Silver
Grounding Type RF connector inner conductor and body grounded to reflector and mounting bracket
Performance Note Outdoor usage
Radiator Material Aluminum
RF Connector Interface N Male
RF Connector Location End of flexible lead
RF Connector Quantity, low band 1
RF Connector Quantity, total 1
Dimensions

Length 5918.2 mm | 233 in
Electrical Specifications

Impedance 50 ohm
Operating Frequency Band 450 – 470 MHz
Polarization Vertical
Electrical Specifications

Frequency Band, MHz 450–470
Gain, dBi 11.3
Beamwidth, Horizontal, degrees 360
Beamwidth, Vertical, degrees 7
VSWR | Return loss, dB 1.5 | 14.0
Input Power per Port, maximum, watts 250
Mechanical Specifications

Wind Loading at Velocity, maximum 133.0 lbf @ 100 mph | 591.6 N @ 100 mph
Wind Speed, maximum 161 km/h | 100.041 mph
Packaging and Weights

Net Weight, without mounting kit 15.6 kg | 34.392 lb
Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
ROHS Compliant
CHINA-ROHS Below maximum concentration value
REACH-SVHC
Read More >>

CommScope / Amphenol - DB420-B - Andrew Omni Exposed Dipole Antenna, 450-470 MHz, 360 deg. Horizontal Beamwidth, Fixed Electrical Tilt

  • Item #: 3225973
  • MFR SKU: DB420-B
  • Lightning Protection: DC Ground
  • Connector Placement: Pigtail
  • Item Weight: 34 lb
  • Vertical Beamwidth: 7 deg
  • Maximum Rated Wind Velocity: 100 mile/h
  • Maximum Power: 250 W
  • Antenna Pattern: Adjustable
  • Tuned Frequency (MHz): 450-470
  • Gain dBd: 11.3 dBd
  • Gain dBi: 11.3 dBi
  • Maximum VSWR: 1.5:1
  • Horizontal Beamwidth: 360 deg
  • RF Connectors: N Male
  • Item Length: 233 in
  • Polarization: Vertical
  • Type of Hardware Included: Pipe Mount (1.25-3.5 in)
  • Jumper Included: Yes
  • Qty/ Uom: 1 Each
  • Specific Frequency: 450-470 MHz
