Image is an illustration, may not reflect the exact product sold.


Other products by Big Joe

Big Joe - WPT45-224AH - WPT45 Electric Power Pallet Jack Truck - 4500 Lb. Cap. - 224AH Batteries

  • MFR SKU: WPT45-224AH
  • ITEM #: 17391137
  • 12345
  • 0 Reviews / 0 Questions
$6,917.60
  • +
    -
  • Saw It For Less?
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 17391137
Big Joe ELECTRIC POWER PALLET JACK TRUCK
For over 50 years, Big Joe products have Improved Worker Productivity and Efficiency.
Power propelled, power lift truck is the logical step-up from a manual truck, as it outperforms two to three operators with manual jacks. 24V AC high-torque drive and lift motors. Multi-function handle allows operation with either hand and features thumb throttle, lift/lower controls, safety reversing switch and horn. Automatic dead-man emergency brake cuts...
ITEM #: 17391137
Big Joe ELECTRIC POWER PALLET JACK TRUCK
For over 50 years, Big Joe products have Improved Worker Productivity and Efficiency.
Power propelled, power lift truck is the logical step-up from a manual truck, as it outperforms two to three operators with manual jacks. 24V AC high-torque drive and lift motors. Multi-function handle allows operation with either hand and features thumb throttle, lift/lower controls, safety reversing switch and horn. Automatic dead-man emergency brake cuts power when handle released. Includes AGM (absorbed gas mat) maintenance free batteries, battery charger, combination battery discharge/hour meter gauge and key switch. Rolls smoothly on polyurethane steer and load wheels. Features 27"W x 45-1/2"L forks, 3-¼" lowered height and 8.2" raised height. 4500 lb. capacity models have 0.9KW drive and 2.2KW lift motors. 2 Year Limited Warranty.
Read More >>

Big Joe - WPT45-224AH - WPT45 Electric Power Pallet Jack Truck - 4500 Lb. Cap. - 224AH Batteries

  • Item #: 17391137
  • MFR SKU: WPT45-224AH
  • br> Product Details
  • Assembly Required Assembled
  • Type Self Propelled
  • Charger Integral 120V
  • Material Steel
  • Style Walkie Pallet Jack Truck
  • Gradeability 10% Unloaded; 6% Loaded
  • Batteries (4) 6 Volt / 224AH
  • Duty Cycle per Charge 6 Hours
  • Warranty 2 yr
  • Color Family Yellow
  • Weights & Dimensions
  • Width 28 in
  • Length 70.9 in
  • Turning Radius 68 in
  • Fork Width 6-11/16 in
  • Travel Speed 3.6 Unloaded; 3.5 Loaded mph
  • Weight Capacity Range 4001 to 5000 lbs
  • Height 48 in
  • Length Range 41 to 45-1/2 in
  • Width Range 26 to 35-1/2 in
  • Lowered Height 3-1/4 in
  • Fork Length 45-1/2 in
  • Weight Capacity 4500 lbs
  • Raised Height 8-3/16 in
  • Weight 1220 lbs
