Ashcroft - A2XBF0215C25#G - Pressure Transmitter: 0 psi to 5 psi, 1 to 5V DC, Cable Wire Leads, IP65 /NEMA 4X/NEMA 7/NEMA 9

  • MFR SKU: A2XBF0215C25#G
  • ITEM #: 4446601
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $732.50 You Save: $174.87
23.87 % OFF
$557.63
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)
Average lead time for this brand: 2-3 weeks. Specific products may vary.

ITEM #: 4446601
These pressure transmitters are rated as explosion-proof to C-UL standards and flameproof to ATEX standards in classified hazardous environments. They’re enclosed within a housing designed to contain an explosion of specific gases or vapors within the transmitter, preventing further ignition of combustible dust or gas in the environment. Transmitters with a 4-20mA output signal are also rated as intrinsically safe and non-incendive in classified hazardous environments to FM and CSA standards....
ITEM #: 4446601
These pressure transmitters are rated as explosion-proof to C-UL standards and flameproof to ATEX standards in classified hazardous environments. They’re enclosed within a housing designed to contain an explosion of specific gases or vapors within the transmitter, preventing further ignition of combustible dust or gas in the environment. Transmitters with a 4-20mA output signal are also rated as intrinsically safe and non-incendive in classified hazardous environments to FM and CSA standards. These transmitters have a 1/2” NPT conduit connection with wire leads, also called bare wires or flying leads.
Read More >>

Ashcroft - A2XBF0215C25#G - Pressure Transmitter: 0 psi to 5 psi, 1 to 5V DC, Cable Wire Leads, IP65 /NEMA 4X/NEMA 7/NEMA 9

  • Item #: 4446601
  • MFR SKU: A2XBF0215C25#G
  • Brand: ASHCROFT
  • Electrical Connection: Cable & Wire Leads ; 1/2 in FNPT Conduit Connection Entry
  • Product Type: Explosion-Proof-Rated Transmitter
  • Output: 1 to 5V DC
  • Pressure Range: 0 psi to 5 psi
  • Accuracy: ± 0.50% of Full Scale
  • Number of Wires: 3
  • Process Connection: 1/4 in NPT Female
  • Safety Rating: Class I, II and III Div. 1 and 2 Groups A, B, C, D, F and G
  • Power Required: 10 to 36V DC
  • Enclosure Rating: IP65 ; NEMA 4X; NEMA 7; NEMA 9
  • Series: A2X
  • Maximum Pressure: 5 psi
  • NEMA Rating: NEMA 4X; NEMA 7; NEMA 9
  • Electrical Connections: Cable & Wire Leads
  • Housing Material: Stainless Steel
  • Fitting Material: Stainless Steel
  • IP Rating: IP65
  • Process Connection Type: NPT
  • Process Connection Size: 1/4 in
  • Minimum Pressure: 0 psi
  • Process Connection Gender: Female
  • Burst Pressure: 2x Range
  • Cable Length: 3 ft
  • Explosion/Fire Proof: Yes
  • Features: Ashcroft’s Proven Thin Film Technology
  • Manufacturers Warranty Length: 1 yr
  • Maximum Operating Temperature: 257 ° F
  • Minimum Operating Temperature: -40 ° F
  • Overall Height: 4.78 in
  • Overall Length: 1.06 in
  • Overall Width: 1.06 in
  • Pressure Units: psi
  • Response Time: 2 msec
  • Standards: ATEX; CE; cUL Listed; RoHS; UL Listed
  • Storage Temperature Range: – 40° F to 257° F (– 40° C to 125° C)
  • Thermal Error: ± 2% (-4° to 185° F)
  • Wiring Entry: 1/2 in FNPT Conduit Connection
  • Overpressure: 1.5x Range
  • UNSPSC: 41112107
  • Country of Origin: USA (subject to change)
