Americraft - AML-36-5-3-EXP - Axial Upblast Roof Exhaust Fan: Direct Drive, 36 in Blade, 21, 200 cfm, TEFC, 5 hp, 230/460V AC, 3

  • MFR SKU: AML-36-5-3-EXP
  • ITEM #: 7901795
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $5,864.00 You Save: $1,343.44
22.91 % OFF
$4,520.56
  • +
    -
  • Saw It For Less?
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 7901795
Flammable vapor fans are used in areas where combustible dust or flammable gases are present. These fans are made with spark-resistant materials or coatings that are designed for use in these conditions. Direct-drive fans have fewer moving parts and typically require less maintenance than belt-drive fans. Each fan features a propeller that's directly mounted on the motor shaft. This reduces friction and improves efficiency compared to a belt-drive fan.

Americraft - AML-36-5-3-EXP - Axial Upblast Roof Exhaust Fan: Direct Drive, 36 in Blade, 21, 200 cfm, TEFC, 5 hp, 230/460V AC, 3

  • Item #: 7901795
  • MFR SKU: AML-36-5-3-EXP
  • Brand: AMERICRAFT FAN
  • For Air Type: Flammable Vapor
  • Drive Type: Direct Drive
  • Includes Drive Package with Motor: Yes
  • Assembly: Assembled
  • Blade Diameter: 36 in
  • Exhaust Airflow @ 0.000 in SP: 21, 200 cfm
  • Exhaust Airflow @ 0.100 in SP: 21, 200 cfm
  • Exhaust Airflow @ 0.125 in SP: 20, 500 cfm
  • Exhaust Airflow @ 0.250 in SP: 19, 500 cfm
  • Exhaust Airflow @ 0.375 in SP: 18, 484 cfm
  • Exhaust Airflow @ 0.500 in SP: 17, 325 cfm
  • Maximum Static Pressure: 1/2 in wc
  • For High-Static Pressure Applications: No
  • Nameplate Voltage: 230/460V AC
  • Phase: 3
  • Current: 7.3 A
  • Frequency: 60 Hz
  • Motor Horsepower: 5 hp
  • Brake Horsepower: 4-3/4 hp
  • Maximum Fan Speed: 1, 140 RPM
  • Motor Speed: 1, 140 RPM
  • Speed Controllable: No
  • Number of Speeds: 1
  • Motor Enclosure: Totally Enclosed Fan Cooled
  • Motor Hazardous Location Rating: Class I Group C; Class I Group D; Class II Group F; Class II Group G
  • High-Efficiency Motor: No
  • Housing Material: Steel
  • Housing Finish: Galvanized
  • Blade Material: Aluminum
  • Number of Blades: 6
  • Maximum Inlet Air Temperature: 104 ° F
  • Maximum Ambient Temperature: 104 ° F
  • Mount Type: Roof Curb
  • Mounting Location: Roof
  • Bearing Type: Ball Bearing
  • Damper Size: 42 x 42 in
  • Base Shape: Square
  • Base Height: 2-1/2 in
  • Base Length: 51 in
  • Base Width: 51 in
  • Housing Length: 42 in
  • Housing Width: 42 in
  • Overall Height: 48-1/2 in
  • Overall Width: 51 in
  • Overall Depth: 51 in
  • Overall Diameter: 36 in
  • Maximum Noise Level @ 5 Feet: 60 sones
  • Sound Level: 60 sones @ 0.250 in SP and 5 ft
  • Application: Designed for General Ventilation, Smoke, and Fume Removal Where Lower Cost and Less Maintenance are a Priority
  • Spark Resistant Construction Type: Not Rated
  • Manufacturer Part Number: AML-36-5-3-EXP
  • Blade Finish: Galvanized
  • Features: Butterfly Damper Section, Damper Blades Open When Fan is Energized and Close Weathertight When Unit is Off; Dampers Rotate in Nylon Bearings on a Stainless Steel Axle; Ruggedly Constructed Steel Curb Cap Including Spun Venturi Section for Efficient Air Flow
  • UNSPSC: 40101502
  • Country of Origin: USA (subject to change)
