AFL Telecommunications - S015590 - 70S Fusion Splicer Kit with Cleaver, ( Each )

ITEM #: 15116599
The Fujikura 70S is the world's fastest and most robust core alignment fusion splicer.
The Fujikura 70S is the world's fastest and most robust core alignment fusion splicer. Incorporating the proven ruggedized features pioneered by Fujikura, the 70S has added automated and enhanced user control features to increase splicing efficiency. A user programmable, automated wind protector expedites the splicing process by automatically closing to initiate the splice process, and opening upon splice completion. Fully programmable auto open sheath clamps open one or both sheath clamps, after the tensile test, to prepare the fiber for removal. A new automated clamshell design tube heater applies heat to both sides of the splice protection sleeve resulting in a 13-second shrink time. The result is a total splice process time of approximately 21 seconds! Ruggedness and durability are greatly enhanced by a mirror-less optical system and severe-impact resistant monitor. Battery capacity is now 200 splices/shrinks. An innovative transit case doubles as a built-in or mobile workstation and makes splicing easier than ever before. S015590 is a 70S Fusion Splicer Kit that includes 70S Fusion Splicer, CT30A Cleaver, ADC-18 AC Adapter, ACC-14 AC Cord, a pair of ELCT2-20A Spare Electrodes, S70C Sheath Clamp, USB Cable, Alcohol Dispenser, Screw Driver, Splicer Carrying Strap, Quick Reference Guide, Video Instruction Manual, and CC30 Transit Case with Carrying Strap.
Features

• Automated and programmable wind protector
• 13-second automated tube heater
• Fully ruggedized for shock, dust and moisture
• Li-ion battery with 200 splices/shrinks per charge
• 5 mm cleave length for splice on connector or small package needs
• Sheath clamp or fiber holder operation
• On-board training and support videos
• Internet software upgrades

Multi-function transit case with integrated workstation
This listing is for Each.
