Image is an illustration, may not reflect the exact product sold.


Other products by TB Wood's / Regal Rexnord

TB Wood's / Regal Rexnord - 6S112 - TB WOOD'S Sleeve Coupling Flange: 6 Coupling Size, 6, 000 RPM Max Speed, 4 in Outside Dia, Cast Iron

  • MFR SKU: 6S112
  • ITEM #: 9290701
  • 12345
  • 0 Reviews / 0 Questions
Lists At: $79.90 You Save: $14.95
18.71 % OFF
$64.95
  • +
    -
Stock Status: SHIPS SOON (reserve your unit today)

ITEM #: 9290701
Plain bore close-coupled flanges mount directly to compatible keyed shafts with tight gap tolerances and join together by a matched sleeve insert.

TB Wood's / Regal Rexnord - 6S112 - TB WOOD'S Sleeve Coupling Flange: 6 Coupling Size, 6, 000 RPM Max Speed, 4 in Outside Dia, Cast Iron

  • Item #: 9290701
  • MFR SKU: 6S112
  • Brand: TB WOOD'S
  • Manufacturer Part Number: 6S112
  • Coupling Size: 6
  • For Shaft Type: Keyed
  • System of Measurement: Inch
  • Bore Type: Round Keyed
  • Bore Diameter: 1-1/2 in
  • Bore Tolerance: +0.0005 in / +0.0015 in
  • Keyway Width: 1/16 in
  • Keyway Depth: 3/8 in
  • Length Through Bore: 1-5/8 in
  • Hub Type: Spacer Hub
  • Hub Diameter: 2-1/2 in
  • Outside Diameter: 4 in
  • Hub Body Length: 17/32 in
  • Hub Material: Cast Iron
  • Maximum Speed: 6, 000 RPM
  • For Misalignment Type: Angular; Parallel
  • Application: Compressors; Conveyors; Motors; Pumps
  • Resistance Properties: Chemical Resistant; Oil Resistant
  • Features: 4-way Flexing Action Absorbs Shock; Misalignment and End Float; Vibration
  • Included Screws: (2) Set Screws
  • Set Screw Location: One Over Keyseat and @ 90 Degrees
  • Screw Thread Size: 5/16'-18
  • Weight: 1.9 lb
  • UNSPSC: 31163003
  • Country of Origin: Mexico (subject to change)
